90
ンㄆㄇㄆㄓㄆㄏㄆ
• If the object type set in the specified object number is not the bar code/2D code, the laser marker returns the negative
response.
• Refer to “2-3-5 Character data input method” (P.37) for details on the character input method and character types with
input restrictions.
• Depending on the barcode/2D code type, acceptable characters may be restricted to either single-byte characters or
double-byte characters. In this case, the input characters are automatically converted to the accepted type.
• When the code data is set in the several string No., the characters in each string No. are connected together in
numerical order without linefeed to create the code data.
• When the code data is set in the several string No., the total input characters should be 299 digits or less.
• To input the control codes in the barcode/2D code data, refer to “Inputting control codes to bar code/2D code character
strings” (P.39).
• For response data for readout, all characters except the functional characters are readout in 2-byte characters (Shift-JIS
code) regardless the settings.
• When the character strings set with the functional character are readout, the setting of the functional character starting
with % are read out. The characters to mark as the functional characters, such as the counter or date and time values,
are not read out.
• With LP-400/V compatible command mode, you cannot readout the character strings with more than 61-byte length.
• With LP-400/V compatible command mode, you cannot set and readout the strings for PDF417, iQR code, QR code for
Chinese characters (GB/T 18284), and CODE93.
• With LP-400/V compatible command mode, you cannot set and readout the strings for QR code with the mode setting
“Auto”.
⿎
Example of command settings
Condition: Object No. = 0, String No. = 1, Code data (counter function and character “abcd”) = %06:C0abcd
• Setting
Transmission data [STX] BRS S 01%06:C0abcd [CR]
• Readout
Transmission data [STX] BRS R 01 [CR]
Response data [STX] BRS A 01%06:C0
ａｂｃｄ
[CR]
