Panasonic Lumix DC-G9 Operating Instructions

Preparation/Basic “Quick Start Guide”
18
DVQX1333 (ENG)
At the time when this camera is purchased, the monitor is stowed in the camera body.
Bring out the monitor as shown below.
1 Open the monitor. (Maximum 180o)
2 It can be rotated 180o forward.
3 Return the monitor to its original position.
• When rotating the monitor, be careful not to apply too much force. Doing so may cause
damage.
• When not using the monitor it is recommended that you close it with the screen facing inward to
prevent dirt and scratches.
• The clock is not set when the camera is shipped.
1 Turn the camera on.
2 Press [MENU/SET].
3 Press 3/4 to select the language, and press [MENU/
SET].
4 Press [MENU/SET].
5 Press 2/1 to select the items (year, month, day,
hour, minute), and press 3/4 to set.
6 Press [MENU/SET] to set.
7 When [The clock setting has been completed.] is
displayed, press [MENU/SET].
8 When [Please set the home area] is displayed, press
[MENU/SET].
9 Press 2/1 to select the home area, and then press
[MENU/SET].
5
Opening the Monitor
6
Setting Date/Time (Clock Set)
DC-G9BodyGH-DVQX1333_eng.book 18 ページ ２０１７年１１月１７日 金曜日 午前１１時４４分

Panasonic Lumix DC-G9 Specifications

General

Sensor Size	17.3 x 13.0 mm (Four Thirds)
Image Processor	Venus Engine
Connectivity	Wi-Fi, Bluetooth
Weight	658 g (body only)
Lens Mount	Micro Four Thirds
Storage Media	Dual SD card slots (UHS-II compatible)
Sensor	Live MOS
ISO Range	ISO 200-25600 (expandable to 100-25600)
Autofocus System	Depth From Defocus (DFD) technology
Viewfinder	OLED Live View Finder, 3, 680k-dot
LCD Screen	3.0" 1, 040k-dot Free-Angle Touchscreen
Video Recording	4K UHD at 60p
Image Stabilization	5-axis in-body stabilization
Burst Shooting	20 fps (electronic shutter)
Battery Life	Approx. 400 shots
Ports	HDMI, USB 3.0
Battery	DMW-BLF19 Lithium-Ion
Dimensions	136.9 x 97.3 x 91.6 mm
Weather Sealing	Yes, Splashproof / Dustproof / Freezeproof
