Panasonic Lumix DC-G9 Operating Instructions

39
Recording
(ENG) DVQX1333
∫ Registering the set AF area to [ ], [ ] or [ ]
1 On the screen in step
3 on P38, press 3.
2 Press 3/4 to select a destination to which the setting will be registered, and press
[MENU/SET].
Specifying the AF area position
• When [Focus Switching for Vert / Hor] in the [Custom] ([Focus / Release Shutter]) menu is set,
the last specified positions of the AF area (when [
Ø], [ ] or [ ] is set) and the MF Assist
display are stored separately for the camera’s horizontal and vertical orientations (two vertical
orientations, left and right, are available).
Applicable modes:
∫ When selecting [š], [ ], [ ], [Ø]
1 Press [ ].
2 Select [š], [ ], [ ] or [Ø] and press 4.
3 Change the position and size of the AF area.
• If you have selected [ ], you can set the lock-on position by changing the AF area
position.
• To specify the person or eye to be brought into focus when [š] has been selected, align
any of the AF areas currently indicating human subjects with the desired person or eye.
For any position where a person or eye is not located, an AF area that operates in the
same way as [Ø] will be set.
• Press [MENU/SET] or touch [ ] to cancel the AF area settings when using [š], [ ] or
[].
4 Press [MENU/SET] to set.
Specifying the AF area position on the setting screen
Button
operation
Touch
operation
Description of operation
3/4/2/1 Touching Moves the position
//
Pinching out/in Changes the size
[DISP.] [Reset]
First time: The position is
reset to the centre
Second time: The size is
reset to the default
ヤヒ
ヤビ
ヤピ
DC-G9BodyGH-DVQX1333_eng.book 39 ページ ２０１７年１１月１７日 金曜日 午前１１時４４分

Panasonic Lumix DC-G9 Specifications

General

Sensor Size	17.3 x 13.0 mm (Four Thirds)
Image Processor	Venus Engine
Connectivity	Wi-Fi, Bluetooth
Weight	658 g (body only)
Lens Mount	Micro Four Thirds
Storage Media	Dual SD card slots (UHS-II compatible)
Sensor	Live MOS
ISO Range	ISO 200-25600 (expandable to 100-25600)
Autofocus System	Depth From Defocus (DFD) technology
Viewfinder	OLED Live View Finder, 3, 680k-dot
LCD Screen	3.0" 1, 040k-dot Free-Angle Touchscreen
Video Recording	4K UHD at 60p
Image Stabilization	5-axis in-body stabilization
Burst Shooting	20 fps (electronic shutter)
Battery Life	Approx. 400 shots
Ports	HDMI, USB 3.0
Battery	DMW-BLF19 Lithium-Ion
Dimensions	136.9 x 97.3 x 91.6 mm
Weather Sealing	Yes, Splashproof / Dustproof / Freezeproof
