Panasonic Lumix DC-G9 Operating Instructions

Recording
40
DVQX1333 (ENG)
∫ When selecting [ ]
1 Press [ ].
2 Select [ ] and press 4.
3 Press 3/4/2/1 to set the focus position and then press [MENU/SET].
4 Move [+] to the position to be in focus.
5 Press [MENU/SET] to set.
Applicable modes:
1 Select the menu.
2 Display the recording screen, and move the
joystick 3/4/2/1 to move the AF area.
• You can change the size of the AF area by
rotating the front/rear dial.
• Press the joystick to switch between the default
AF area position and the position you have set.
The enlarged display will appear when [ ]
([Pinpoint]) is set.
3 Press the shutter button halfway to set.
• Press the joystick while the recording screen is displayed to switch between the default
AF area position and the position you have set.
Button
operation
Touch operation Description of operation
3/4/2/1 Touching Moves [+].
/ Pinching out/in Enlarges/reduces the screen.
Switches the enlarged display
(windowed/full screen).
[DISP.] [Reset] Returns you to the screen in step 3.
Specifying the AF area position with the joystick
> [Custom] > [Operation] > [Joystick Setting] > [D.FOCUS
Movement]
MENU
DC-G9BodyGH-DVQX1333_eng.book 40 ページ ２０１７年１１月１７日 金曜日 午前１１時４４分

Panasonic Lumix DC-G9 Specifications

General

Sensor Size	17.3 x 13.0 mm (Four Thirds)
Image Processor	Venus Engine
Connectivity	Wi-Fi, Bluetooth
Weight	658 g (body only)
Lens Mount	Micro Four Thirds
Storage Media	Dual SD card slots (UHS-II compatible)
Sensor	Live MOS
ISO Range	ISO 200-25600 (expandable to 100-25600)
Autofocus System	Depth From Defocus (DFD) technology
Viewfinder	OLED Live View Finder, 3, 680k-dot
LCD Screen	3.0" 1, 040k-dot Free-Angle Touchscreen
Video Recording	4K UHD at 60p
Image Stabilization	5-axis in-body stabilization
Burst Shooting	20 fps (electronic shutter)
Battery Life	Approx. 400 shots
Ports	HDMI, USB 3.0
Battery	DMW-BLF19 Lithium-Ion
Dimensions	136.9 x 97.3 x 91.6 mm
Weather Sealing	Yes, Splashproof / Dustproof / Freezeproof
