Panasonic Lumix DC-GX9 Basic Operating Instructions

17
DVQX1391 (ENG)
Preparations/Basics
Inserting the battery and/or SD memory card (optional)
Make sure that the camera is turned off.
1
Slide the release lever ( ) to the [OPEN]
position and open the card/battery door
[OPEN]
[LOCK]
2
Insert the battery and card,
making sure that their
orientation is correct ( )
• Battery: Insert the battery all the way
firmly and check that it is
locked by lever (
).
• Card: Insert the card all the way firmly
until it clicks. Do not touch the
terminal.
3
Close the door
Slide the release lever to the [LOCK] position.
■
To remove
• To remove battery
Move lever (
) in direction of
arrow.
• To remove card
Press the centre of the card.
Press
Pull out
●
Always use genuine Panasonic batteries (DMW-BLG10E).
●
If you use other batteries, we cannot guarantee the quality of this product.
●
If you close the card/battery door with the battery not inserted all the way, the
battery may pop out.

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
