Panasonic Lumix DC-GX9 Basic Operating Instructions

21
DVQX1391 (ENG)
Preparations/Basics
Extending/retracting the lens [when the interchangeable
lens (H-FS12032/H-FS35100) is attached]
■
How to Extend the Lens
Rotate the zoom ring in the direction of arrow from
position (
) (the lens is retracted) to position ( ) [12 mm
to 32 mm (H-FS12032), 35 mm to 100 mm (H-FS35100)] to
extend the lens.
• When the lens barrel is retracted, images cannot be
recorded.
The lens is retracted
Example: H-FS12032
■
How to Retract the Lens
Rotate the zoom ring in the direction of arrow from
position (
) [12 mm to 32 mm (H-FS12032), 35 mm to
100 mm (H-FS35100)] to position (
) to retract the lens.
• The zoom ring will seem to click into the 12 mm position
(H-FS12032) or 35 mm position (H-FS35100), but
continue to rotate the lens until it reaches position (
).
• When you are not recording images, we recommend that
you retract the lens.
The lens is extended
Formatting the card (initialisation)
Format the card before recording a picture with this unit.
Since data cannot be recovered after formatting, make sure to back up
necessary data in advance.
→ [Setup] → [Format]

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
