Panasonic Lumix DC-GX9 Basic Operating Instructions

22
Preparations/Basics
DVQX1391 (ENG)
[LVF] button (Recording pictures using the viewfinder)
1
Press [LVF] ( ) button
[LVF] button
Eye Sensor
Automatic switching between
viewfinder and monitor

Viewfinder display

Monitor display

When [Eye Sensor AF] in the [Custom] ([Focus / Release Shutter]) menu is set to [ON], the
camera adjusts the focus automatically as the eye sensor is activated. Even when [Eye Sensor
AF] is set and the camera automatically adjusts the focus, a beep will not sound.
■
Automatic switching between viewfinder
and monitor
The eye sensor ( ) automatically switches the display
to viewfinder when your eye or an object moves close to
the viewfinder. When the eye or object moves away from
the viewfinder, the camera returns to monitor display.
●
Battery drainage can be suppressed by setting [Power Save LVF Shooting] in
[Economy].
●
The eye sensor does not work depending on the angle of the monitor.
■
About dioptre adjustment
Open the viewfinder
Rotate the dioptre adjustment dial
• Rotate it to adjust until you are able to
clearly see the characters displayed in the
viewfinder.

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
