Panasonic Lumix DC-GX9 Basic Operating Instructions

34
Recording
DVQX1391 (ENG)
• Colour is added to the portions of the image that
are in focus. (Peaking)
• You can check whether the point of focus is to the
near side or to the far side. (MF Guide)
• MF Assist and MF Guide may not display
depending on the lens used. You can, however,
display MF Assist by directly operating the
camera using the touch screen or a button.
MF Assist (Enlarged screen)
Peaking
MF Guide
Operation Touch operation Description

1
Drag Moves the enlarged area.
Pinch out /
Pinch in
Enlarges/reduces the screen in small steps.
— Enlarges/reduces the screen in large steps.

2

2
Switches the enlarged display. (windowed/full screen)
[DISP.]

1
[Reset]

1
Resets the area to be enlarged back to the centre.

1
When using an interchangeable lens with no focus ring, you can perform these operations
after pressing
to display the screen that lets you set the area to be enlarged.

2
This setting is not available in Intelligent Auto Mode.
5 Press the shutter button halfway
• The recording screen will be displayed.

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
