Panasonic Lumix DC-GX9 Basic Operating Instructions

92
DVQX1391 (ENG)
Others
Interchangeable Lens H-FS14140
“LUMIX G VARIO 14–140 mm/F3.5–5.6 ASPH./POWER O.I.S.”
Focal length f=14 mm to 140 mm
(35 mm film camera equivalent: 28 mm to 280 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Maximum aperture F3.5 (Wide) to F5.6 (Tele)
Minimum aperture
value
F22
Lens construction 14 elements in 12 groups
(3 aspherical lenses, 2 ED lenses)
In focus distance 0.3 m (0.98 feet) to
(from the focus distance reference line)
(focal length 14 mm to 21 mm),
0.5 m (1.6 feet) to
(from the focus distance reference line)
(focal length 22 mm to 140 mm)
Maximum image
magnification
0.25x (35 mm film camera equivalent: 0.5x)
Optical Image Stabiliser Available
[O.I.S.] switch Available (Switching ON/OFF)
Mount “Micro Four Thirds Mount”
Angle of view 75° (Wide) to 8.8° (Tele)
Filter diameter 58 mm
Max. diameter Ø 67 mm (2.6 inch)
Overall length Approx. 75 mm (3.0 inch)
(from the tip of the lens to the base side of the lens mount)
Mass Approx. 265
/0.58 lb
Dust-proof and splash-
proof
None

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
