- 7 -
Before Use
Names of the Components
1Flash (P43)
2Lens (P112)
3 Self-timer indicator (P49)
AF assist lamp (P78)
4 Microphone (P62)
5 LCD monitor (P42, 107)
6 [MENU/SET] button (P17)
7 [DISPLAY] button (P42)
8 [Q.MENU] (P22)/Delete (P40) button
9 [MODE] button (P27)
10 [REC]/[PLAYBACK] selector switch
(P19)
11 Cursor buttons
A: 3/Exposure compensation (P50)
B: 4/Macro Mode (P48)
C: 2/Self-timer button (P49)
D: 1/Flash setting button (P43)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
1 2
4
3
5
1110
68
9
7
