VQT1M59
82
Advanced (Playback)
If you press [MENU/SET] while canceling protection, the canceling will stop halfway.
Note
The protect setting may not be effective on other equipment.
Even if you protect pictures in the built-in memory or a card, they will be deleted if the built-in
memory or the card is formatted.
Even if you do not protect pictures on an SD Memory Card or an SDHC Memory Card, they
cannot be deleted when the cards Write-Protect switch is set to [LOCK].
You can copy the data of the pictures you have taken from the built-in memory to a card or
from a card to the built-in memory.
Select [COPY] on the [PLAYBACK] mode menu. (P19)
Move 3/4 to select the copy destination and then
press [MENU/SET].
Move 2/1 to select the picture and then press [MENU/SET].
Move 3 to select [YES], and then press [MENU/
SET].
If you press [MENU/SET] while copying pictures from the built-in
memory to the card, the copying will stop halfway.
Do not turn the camera off at any point during the copying process.
Press [] to return to the menu screen.
Press [MENU/SET] to close the menu.
If you copy from the built-in memory to a card, all the pictures are copied and then the
screen automatically returns to the playback screen.
Note
If you copy picture data from the built-in memory to a card which does not have sufficient free
space, the picture data will only be copied halfway. We recommend using a card which has
more free space than the built-in memory (about 50 MB).
If a picture exists with the same name (folder number/file number) as the picture to be copied in
the copy destination when [ ] is selected, a new folder is created and the picture is copied.
If a picture exists with the same name (folder number/file number) as the picture to be copied in
the copy destination when [ ] is selected, that picture is not copied. (P95)
It may take time to copy the picture data.
Only pictures recorded with a Panasonic digital camera (LUMIX) will be copied.
(Even if the pictures were recorded with a Panasonic digital camera, you may not be able to
copy them if they were edited with a PC.)
DPOF settings on the original picture data will not be copied. Set the DPOF settings again after
copying is finished.
S [COPY]
: All the picture data in the built-in memory are copied onto
the card at one time. > step
4.
: One picture at a time is copied from the card to the built-in
memory. > step
3.
1
2
3
4
5
VQT1M59_ENG.book 82 ージ 2008年1月8日 火曜日 午後5時21分

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS20 and is the answer not in the manual?

Panasonic Lumix DMC-FS20 Specifications

General IconGeneral
Megapixel10.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Maximum image resolution3648 x 2736 pixels
Digital zoom4 x
Focal length range5.2 - 20.8 mm
InterfaceUSB 2.0, AV out
Digital SLRNo
Camera shutter speed8 - 1/2000 s
Focal length (35mm film equivalent)30 - 120 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesmulti point auto focus, single auto focus
Auto Mode focusing range (tele)1 - ∞ m
Auto Mode focusing range (wide)0.1- ∞ m
Flash modesauto, Red-eye reduction
Flash range (tele)0.3 - 3.1 m
Flash range (wide)0.6 - 6.3 m
Internal memory50 MB
Compatible memory cardsmmc, sd, sdhc
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution848 x 480 pixels
Display diagonal3 \
USB version2.0
Scene modesbeach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, party (indoor), Portrait, self-portrait, Sports, Sunset, Landscape (scenery)
Image editingresizing, rotating, trimming
Photo effectsblack&white, Sepia, Vivid
White balanceauto, Cloudy, custom modes, daylight, Fluorescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2, 10 s
Product colorBlack
Battery type3.6V
Battery capacity1000 mAh
Number of batteries supported1
Bundled softwareArcSoft MediaImpression ArcSoft PanoramaMaker PhotofunStudio
Weight and Dimensions IconWeight and Dimensions
Depth23 mm
Width95 mm
Height57 mm
Weight130 g
