93
VQT1M59
Others
the surrounding temperature and humidity. If the temperature is too high or too low,
the operating time of the battery will become shorter.
Always remove the battery after use.
Store the removed battery in the battery carrying case (supplied).
If you drop the battery accidentally, check to see if the
body of the battery and the terminals are damaged.
Inserting a damaged battery in the camera will damage the
camera.
Bring charged spare batteries when going out.
Be aware that the operating time of the battery becomes shorter
in low temperature conditions such as at a ski resort.
When you travel, do not forget to bring the battery charger (supplied) so that you can charge
the battery in the country that you are traveling in.
Dispose of unusable battery.
The battery has a limited life.
Do not throw the battery into fire because it may cause an explosion.
The unusable battery should be discarded in accordance with battery recycling laws. Call the
RBRC hotline at 1-800-822-8837 for information.
Do not allow battery terminals to come into contact with metal objects (such as
necklaces, hairpins etc.).
This can cause short circuiting or heat generation and you may be badly burned if you touch a battery.
If you use the battery charger near a radio, the radio reception may be disturbed.
Keep the charger 1 m (3.28 feet) or more away from radios.
The charger may generate whirring sounds when it is being used. This is not a malfunction.
After use, be sure to disconnect the power supply device from the electrical outlet. (A very small
amount of current is consumed if it is left connected.)
Keep the terminals of the charger and battery clean.
Do not leave the card where the temperature is high, where electromagnetic waves
or static electricity are easily generated or exposed to direct sunlight.
Do not bend or drop the card.
The card may be damaged or the recorded content may be damaged or deleted.
Put the card in the card case or the storage bag after use and when storing or carrying the card.
Do not allow dirt, dust or water to get into the terminals on the back of the card and do not touch
the terminals with your fingers.
Store the battery in a cool and dry place with a relatively stable temperature: [Recommended
temperature:15 oC to 25 oC (59 oF to 77 oF), Recommended humidity: 40% to 60%]
Always remove the battery and the card from the camera.
If the battery is left inserted in the camera, it will discharge even if the camera is turned off. If
the battery continues to be left in the camera, it will discharge excessively and may become
unusable even if charged.
When storing the battery for a long period of time, we recommend charging it once a year.
Remove the battery from the camera and store it again after it has completely discharged.
We recommend storing the camera with a desiccant (silica gel) when you keep it in a closet or a cabinet.
Charger
Card
When not using the camera for a long period of time
VQT1M59_ENG.book 93 ージ 2008年1月8日 火曜日 午後5時21分

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS20 and is the answer not in the manual?

Panasonic Lumix DMC-FS20 Specifications

General IconGeneral
Megapixel10.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Maximum image resolution3648 x 2736 pixels
Digital zoom4 x
Focal length range5.2 - 20.8 mm
InterfaceUSB 2.0, AV out
Digital SLRNo
Camera shutter speed8 - 1/2000 s
Focal length (35mm film equivalent)30 - 120 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesmulti point auto focus, single auto focus
Auto Mode focusing range (tele)1 - ∞ m
Auto Mode focusing range (wide)0.1- ∞ m
Flash modesauto, Red-eye reduction
Flash range (tele)0.3 - 3.1 m
Flash range (wide)0.6 - 6.3 m
Internal memory50 MB
Compatible memory cardsmmc, sd, sdhc
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution848 x 480 pixels
Display diagonal3 \
USB version2.0
Scene modesbeach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, party (indoor), Portrait, self-portrait, Sports, Sunset, Landscape (scenery)
Image editingresizing, rotating, trimming
Photo effectsblack&white, Sepia, Vivid
White balanceauto, Cloudy, custom modes, daylight, Fluorescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2, 10 s
Product colorBlack
Battery type3.6V
Battery capacity1000 mAh
Number of batteries supported1
Bundled softwareArcSoft MediaImpression ArcSoft PanoramaMaker PhotofunStudio
Weight and Dimensions IconWeight and Dimensions
Depth23 mm
Width95 mm
Height57 mm
Weight130 g
