Panasonic Lumix DMC-FS45 User Manual

Others
- 118 -
[Please turn camera off and then on again]/[System Error]
•
This message appears when the camera is not operating properly.
> Turn the camera off and on. If the message persists, contact the dealer or your nearest
Service Centre.
[Memory Card Error]/[Memory card parameter error]/[This memory card cannot be
used]
> Use a card compatible with this unit. (P16)
– SD Memory Card (8 MB to 2 GB)
– SDHC Memory Card (4 GB to 32 GB)
– SDXC Memory Card (48 GB, 64 GB)
[Insert SD card again]/[Try another card]
•
An error has occurred accessing the card.
> Insert the card again.
> Insert a different card.
[Read Error/Write Error
Please check the card]
•
It has failed to read or write data.
> Remove the card after turning the power [OFF]. Insert the card again, turn the power on,
and try to read or write the data again.
• The card may be broken.
> Insert a different card.
[Motion recording was cancelled due to the limitation of the writing speed of the
card]
•
Use a card with SD Speed Class with “Class 4” or higher when recording motion pictures.
• In the event that it stops even after using a “Class 4” card or higher, the data writing speed has
deteriorated so it is recommended to make a backup and then format (P44).
• Depending on the type of the card, motion picture recording may stop in the middle.
[Cannot record due to incompatible format(NTSC/PAL) data on this card.]
> Format the card after saving necessary data on a PC etc. (P44)
> Insert a different card.
[A folder cannot be created]
•
A folder cannot be created because there are no remaining folder numbers that can be used.
> Format the card after saving necessary data on a PC etc. (P44)
[Picture is displayed for 16:9 TV]/[Picture is displayed for 4:3 TV]
•
Select [TV Aspect] in the [Setup] menu if you want to change the TV aspect. (P43)
• This message also appears when the USB connection cable is connected to the camera only.
In this case, connect the other end of the USB connection cable to a PC or a printer. (P102,
105)
[This battery cannot be used]
•
Use a genuine Panasonic battery. If this message is displayed even when a genuine
Panasonic battery is used, contact the dealer or your nearest Service Centre.
• If the battery terminal is dirty, clean it and remove any objects.

Panasonic Lumix DMC-FS45 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	3456x3456, 4608x3456, 3648x2736, 2560x1920, 2048x1536, 640x480, 4608x3072, 4608x2592
Digital zoom	4 x
Optical zoom	5 x
Extra/Smart zoom	11.3 x
Focal length range	4.3 - 21.5 mm
Maximum aperture number	6.4
Minimum aperture number	2.5
Number of aspheric elements	3
Lens structure (elements/groups)	6/5
Maximum focal length (35mm film equiv)	130 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/1 - ∞ m
Auto Focus (AF) points	23
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Light exposure modes	-
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.1 m
Flash range (wide)	0.4 - 5.6 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	25 fps
Video formats supported	MP4
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Memory slots	1
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Silver
Scene modes	Children, Close-up (macro), Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Image editing	Crop, Resizing
Photo effects	Black&White, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Movie, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	3.6 V
Battery capacity	680 mAh
Cables included	USB
Bundled software	PHOTOfunSTUDIO 8.0 Standard Edition\\r Adobe Reader

Weight and Dimensions

Depth	19.4 mm
Width	96 mm
Height	57.1 mm
Weight	106 g
Weight (including battery)	123 g
