- 119 -
Others
Troubleshooting
First, try out the following procedures (P119127).
This phenomenon occurs when charging in a location where the temperature is very high or
very low.
> Reconnect the USB connection cable (supplied) in a location where the ambient
temperature (and the temperature of battery) is in a 10 oC to 30 oC (50 oF to 86 oF) range,
and try charging again. [If you reconnect the USB connection cable (supplied) when the
unit is fully charged, the charging lamp will turn on for approximately 15 seconds.]
The battery is exhausted. Charge the battery.
If you leave the camera on, the battery will be exhausted.
> Turn the camera off frequently by using the [Sleep Mode]. (P42)
Insert the battery securely all the way in. (P10)
Is the REC/PLAY switch at the [!] setting? (P22)
Is there any memory remaining on the built-in memory or the card?
> Delete the pictures which are not necessary to increase available space in the memory.
(P35)
You may not be able to record for a short while after turning the power [ON] when using a large
capacity card.
The picture can become whitish if there is dirt, e.g. fingerprints on the lens.
> If the lens is dirty, turn on the camera, eject the lens barrel and gently wipe the lens surface
with a soft, dry cloth.
> Check that the exposure is correctly compensated. (P54)
> Set [Burst] (P71) of the [Rec] menu to [OFF].
If the problem is not resolved, it may be improved by selecting [Reset] (P43) on the
[Setup] menu.
Battery and power source
The charging lamp has gone off but the unit has not been charged.
The camera cannot be operated even when it is turned on.
The camera turns off immediately after it is turned on.
Card/battery door does not close.
Recording
The picture cannot be recorded.
The recorded picture is whitish.
The recorded picture is too bright or dark.
Multiple pictures are taken at one time.

Table of Contents

Other manuals for Panasonic Lumix DMC-FS45

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS45 and is the answer not in the manual?

Panasonic Lumix DMC-FS45 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedEXIF, JPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)3456x3456, 4608x3456, 3648x2736, 2560x1920, 2048x1536, 640x480, 4608x3072, 4608x2592
Digital zoom4 x
Optical zoom5 x
Extra/Smart zoom11.3 x
Focal length range4.3 - 21.5 mm
Maximum aperture number6.4
Minimum aperture number2.5
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)130 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞/1 - ∞ m
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Light exposure modes-
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 2.1 m
Flash range (wide)0.4 - 5.6 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720 pixels
Motion JPEG frame rate25 fps
Video formats supportedMP4
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Memory slots1
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorSilver
Scene modesChildren, Close-up (macro), Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Image editingCrop, Resizing
Photo effectsBlack&White, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
Playback zoom (max)16 x
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage3.6 V
Battery capacity680 mAh
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 8.0 Standard Edition\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth19.4 mm
Width96 mm
Height57.1 mm
Weight106 g
Weight (including battery)123 g
