- 23 -
Basic
Recording Mode:
Taking pictures using the automatic function
(Intelligent Auto Mode)
The camera will set the most appropriate settings to match the subject and the recording
conditions so we recommend this mode for beginners or those who want to leave the
settings to the camera and take pictures easily.
The following functions are activated automatically.
Scene Detection/Backlight Compensation/Intelligent ISO sensitivity control/Auto White
Balance/Face Detection/[i.Exposure]/[i.Resolution]/[i.ZOOM]/[AF Assist Lamp]/
[Red-Eye Removal]/[Stabilizer]/[Continuous AF]
Slide the REC/PLAY switch to [!],
and then press [MODE].
Press 3/4/2/1 to select [Intelligent Auto],
and then press [MENU/SET].
Press the shutter button halfway to focus.
The focus indication 1 (green) lights when the subject
is focused.
The AF area 2 is displayed around the subject’s face
by the Face Detection function. In other cases, it is
displayed at the point on the subject which is in focus.
The minimal distance (how close you can be to the
subject) will change depending on the zoom factor.
Please check with the recordable range display on
the screen.
(P27)
You can set the AF tracking by pressing 3. For details,
refer to P69. (AF tracking is cancelled by pressing 3
again)
Press the shutter button fully (push it in
further), and take the picture.
1
2

Table of Contents

Other manuals for Panasonic Lumix DMC-FS45

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS45 and is the answer not in the manual?

Panasonic Lumix DMC-FS45 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedEXIF, JPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)3456x3456, 4608x3456, 3648x2736, 2560x1920, 2048x1536, 640x480, 4608x3072, 4608x2592
Digital zoom4 x
Optical zoom5 x
Extra/Smart zoom11.3 x
Focal length range4.3 - 21.5 mm
Maximum aperture number6.4
Minimum aperture number2.5
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)130 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞/1 - ∞ m
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Light exposure modes-
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 2.1 m
Flash range (wide)0.4 - 5.6 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720 pixels
Motion JPEG frame rate25 fps
Video formats supportedMP4
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Memory slots1
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorSilver
Scene modesChildren, Close-up (macro), Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Image editingCrop, Resizing
Photo effectsBlack&White, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
Playback zoom (max)16 x
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage3.6 V
Battery capacity680 mAh
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 8.0 Standard Edition\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth19.4 mm
Width96 mm
Height57.1 mm
Weight106 g
Weight (including battery)123 g
