Recording
- 52 -
Applicable modes:
Taking Close-up Pictures ([AF Macro]/[Macro Zoom])
This mode allows you to take close-up pictures of a subject, e.g. when taking pictures of
flowers.
Press 4 [#].
Press 3/4 to select the item and then press [MENU/SET].
Note
We recommend using a tripod and the Self-timer.
We recommend setting the flash to [Œ] when you take pictures at close range.
If the distance between the camera and the subject is beyond the focus range of the camera,
the picture may not be properly focused even if the focus indication lights.
When a subject is close to the camera, the effective focus range is significantly narrowed.
Therefore, if the distance between the camera and the subject is changed after focusing on the
subject, it may become difficult to focus on it again.
Macro Mode gives priority to a subject close to the camera. Therefore, if the distance between
the camera and the subject is far, it takes longer to focus on it.
When you take pictures at close range, the resolution of the periphery of the picture may
decrease slightly. This is not a malfunction.
[Macro Zoom] cannot be set in the following cases.
When in Miniature Effect Mode
When [AF Mode] is set to [ ]
When [Burst] is set to [ ] or [ ]
Item Description of settings
[]([AF Macro])
You can take pictures of a subject as close as 5 cm
(0.16 feet) from the lens by rotating the zoom lever
upmost to Wide (1k).
[] ([Macro Zoom])
Use this setting to get close to the subject and then
further enlarge when taking the picture.
You can take a picture with the Digital Zoom up to 3k
while maintaining the distance to the subject for the
extreme Wide position [5 cm (0.16 feet)].
The image quality is poorer than during normal recording.
Zoom range will be displayed in blue. (digital zoom range)
[OFF]
j

Table of Contents

Other manuals for Panasonic Lumix DMC-FS45

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS45 and is the answer not in the manual?

Panasonic Lumix DMC-FS45 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedEXIF, JPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)3456x3456, 4608x3456, 3648x2736, 2560x1920, 2048x1536, 640x480, 4608x3072, 4608x2592
Digital zoom4 x
Optical zoom5 x
Extra/Smart zoom11.3 x
Focal length range4.3 - 21.5 mm
Maximum aperture number6.4
Minimum aperture number2.5
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)130 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞/1 - ∞ m
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Light exposure modes-
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 2.1 m
Flash range (wide)0.4 - 5.6 m
Power source typeBattery
Video resolutions640 x 480, 1280 x 720 pixels
Motion JPEG frame rate25 fps
Video formats supportedMP4
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Memory slots1
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorSilver
Scene modesChildren, Close-up (macro), Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Image editingCrop, Resizing
Photo effectsBlack&White, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
Playback zoom (max)16 x
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage3.6 V
Battery capacity680 mAh
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 8.0 Standard Edition\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth19.4 mm
Width96 mm
Height57.1 mm
Weight106 g
Weight (including battery)123 g
