NOTE: (When Installing)
Make sure to confirm the following points when installing:
• The Screw is tightened enough.
• Installing conditions are fine. (No distortion, no abnormal-
space.)
• No dust and/or dirt on image sensor surface. (live mos)
• LCD image is fine. (No dust and/or dirt on it, and no gradient
images.)
9.2. Disassembly and Assembly
Procedure for the Lens
Please refer to the following service manuals about Disassem-
bly and Assembly of bundled lenses.
• H-FS14140PP/E/GK: Order No.DSC1305023CE
• H-FS1442APP/E/GK: Order No.DSC1302014CE
• H-FS45150PP/E/GK: Order No.DSC1209040CE
To Next Page
