Panasonic Lumix DMC-GH2 User Manual

VQT3A36
170
Others
Others
Optional accessories
After attaching the external flash (DMW-FL220, DMW-FL360, DMW-FL500; optional), the
effective range will be increased when compared to the camera’s built in flash.
Preparations:
•
Turn off the camera and close the built-in flash.
∫ Using the dedicated flash (DMW-FL220; optional)
Attach the dedicated flash to the hot shoe and then turn on the
camera and the dedicated flash.
Select [FLASH] on the [REC] Mode menu. (P55)
Press 3/4 to select the mode and then press [MENU/SET].
• While the external flash is connected, the following icons are displayed.
∫ When using other commercially available external flashes without
communication functions with the camera (DMC-GH2)
•
It is necessary to set the exposure on the external flash. If you want to use the external flash in
Auto Mode, use an external flash that allows you to set the aperture value and the ISO
sensitivity to match the settings on the camera.
• Set to Aperture-Priority AE Mode or Manual Exposure Mode on the camera and then set the
same aperture value and ISO sensitivity on the external flash. (The exposure cannot be
compensated adequately due to the change on the aperture value in Shutter-Priority AE Mode
and the external flash cannot control the light adequately in Program AE Mode because the
aperture value cannot be fixed.)
Note
•
You can set the aperture value, the shutter speed and the ISO sensitivity on the camera even
when attaching the external flash.
• Some commercial external flashes have synchro terminals with high-voltage or reversed
polarity. Using such extra flashes may cause a malfunction or the camera may not operate
normally.
• If you use commercially available external flashes with communication functions other than the
dedicated one, they may not operate normally or they may be damaged. Do not use them.
• Even if the external flash is turned off, the camera may enter the external flash mode when the
external flash is attached. When you are not using the external flash, detach it.
• Do not open the built-in flash when an external flash is attached.
• The camera will become unstable when attaching the external flash, it is recommended to use
a tripod when taking picture.
• Detach the external flash when carrying the camera.
• The built in flash is disabled when an external flash is attached.
• If you use the external flash when the White Balance is set to [ ] finely adjust the White
Balance depending on the picture quality. (P89)
External Flash (optional)
: External flash Forced ON
: External flash Slow Sync.
DMC-GH2H&GH2K&GH2PP-VQT3A36_eng.book 170 ページ ２０１０年１０月１９日 火曜日 午前１１時３分

Panasonic Lumix DMC-GH2 Specifications

General

Megapixel	16.05 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	3264 x 2448, 3456 x 3456, 4608 x 3456, 4752 x 3168
Filter size	62 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 140 mm
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 250, 500, 640, 800, 1600, 2000, 6400, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Pre-flash, Red-eye reduction, Slow synchronization
Digital SLR	No
Power source type	Battery
Camera shutter speed	60 - 1/4000 s
Scene modes	Children, Close-up (macro), Dawn, Night, Night landscape, Night portrait, Party (indoor), Portrait, Sports
Image editing	Resizing, Rotating
Photo effects	Black&White, Skin tones
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Battery capacity	1200 mAh
Battery life (CIPA standard)	340 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 6.0 HD Edition SILKYPIX Developer Studio 3.1 SE Super Loilo Scope

Weight and Dimensions

Depth	75.8 mm
Width	124 mm
Height	89.6 mm
Weight	609 g
