Panasonic Lumix DMC-GH2 User Manual

VQT3A36
172
Others
If you use the stereo microphone (DMW-MS1; optional), you can switch to either stereo or
monaural sound recording.
It is also possible to reduce the wind noise efficiently by switching the [WIND CUT OFF/
ON] switch to [ON].
Battery Check Lamp [BATTERY]
•
When the Off/On Mode Selector Switch is changed from [OFF] to [MONO] or [STEREO], the
Battery Check Lamp [BATTERY] will light temporarily if there is still plenty of power in the
battery. If the Battery Check Lamp [BATTERY] does not light temporarily, replace the battery
with a new one.
Note
•
While the external microphone is connected, [ ] is displayed on the screen.
• When the external microphone is connected, [MIC LEVEL DISP.] (P128) is automatically set to
[ON], and the mic level is displayed on the screen.
• When attaching the stereo microphone, do not hold only the stereo microphone because it may
detach from the camera.
• Set the wind noise reduction only on the stereo microphone side.
• Do not open the built-in flash when the stereo microphone is attached.
• The stereo microphone cannot be used while the external flash (optional) is in use.
• The stereo microphone cannot be used while the remote shutter (DMW-RSL1; optional) is in
use.
• Read the operating instructions of the stereo microphone for details.
By connecting the AC adaptor (DMW-AC8PP; optional) and the DC coupler (DMW-DCC8;
optional), and then plugging them into an electrical socket, you can connect this unit to a
PC or printer and use without worrying about the capacity of the battery.
Note
•
Always use a genuine Panasonic AC adaptor (DMW-AC8PP; optional).
• Always use a genuine Panasonic DC coupler (DMW-DCC8; optional).
• Also read the operating instructions for the AC adaptor and DC coupler.
External Microphone (optional)
AC adaptor (optional)/DC coupler (optional)
DMC-GH2H&GH2K&GH2PP-VQT3A36_eng.book 172 ページ ２０１０年１０月１９日 火曜日 午前１１時３分

Panasonic Lumix DMC-GH2 Specifications

General

Megapixel	16.05 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	3264 x 2448, 3456 x 3456, 4608 x 3456, 4752 x 3168
Filter size	62 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 140 mm
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 250, 500, 640, 800, 1600, 2000, 6400, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Pre-flash, Red-eye reduction, Slow synchronization
Digital SLR	No
Power source type	Battery
Camera shutter speed	60 - 1/4000 s
Scene modes	Children, Close-up (macro), Dawn, Night, Night landscape, Night portrait, Party (indoor), Portrait, Sports
Image editing	Resizing, Rotating
Photo effects	Black&White, Skin tones
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Battery capacity	1200 mAh
Battery life (CIPA standard)	340 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 6.0 HD Edition SILKYPIX Developer Studio 3.1 SE Super Loilo Scope

Weight and Dimensions

Depth	75.8 mm
Width	124 mm
Height	89.6 mm
Weight	609 g
