Panasonic Lumix DMC-GH2 User Manual

VQT3A36
192
Others
> Disconnect the USB connection cable. Connect it again while the card is inserted in the
camera.
> Check if your PC is compatible with SDXC memory cards.
http://panasonic.net/avc/sdcard/information/SDXC.html
> A message prompting to format the card may be displayed when connecting, but do not
format.
> If the [ACCESS] displayed on the LCD monitor does not disappear, disconnect the
USB
connection cable
after turning off the power.
• Pictures cannot be printed using a printer which does not support PictBridge.
> Set to [PictBridge(PTP)] in [USB MODE]. (P60, 166)
> When using a printer with a Cropping or borderless printing function, cancel this function
before printing. (For details, refer to the operating instructions for the printer.)
> When you order photo studios to print pictures, ask the photo studio if the pictures can be
printed with both ends.
• This is the noise of the Dust Reduction Function working (P177); it is not a malfunction.
• It is a sound of lens movement or aperture operation when the power is turned [ON] or [OFF],
and it is not a malfunction.
• You may hear a sound from the lens and image in the LCD monitor may suddenly change when
the brightness has changed by zoom operation or moving the camera, but there is no effect on
recording.
The sound is caused by the automatic adjustment of the aperture. This is not a malfunction.
> Press [MENU/SET], select the [SETUP] menu icon [ ] and then select the [~] icon to set
the desired language. (P62)
• This is a highlight function showing the white saturated area. (P129)
• Is the [HIGHLIGHT] set to [ON]?
• In dark places, the AF Assist Lamp (P131) lights red to make it easier to focus on a subject.
The card is not recognized by the PC.
The card is not recognized by the PC. (SDXC memory card is used)
The picture cannot be printed when the camera is connected to a printer.
The ends of the pictures are cut at printing.
Others
The camera makes a noise when turned [ON].
There is a sound from lens unit.
An unreadable language was selected by mistake.
Part of the picture is flashing in black and white.
A red lamp sometimes turns on when the shutter button is pressed halfway.
DMC-GH2H&GH2K&GH2PP-VQT3A36_eng.book 192 ページ ２０１０年１０月１９日 火曜日 午前１１時３分

Panasonic Lumix DMC-GH2 Specifications

General

Megapixel	16.05 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	3264 x 2448, 3456 x 3456, 4608 x 3456, 4752 x 3168
Filter size	62 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 140 mm
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 250, 500, 640, 800, 1600, 2000, 6400, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Pre-flash, Red-eye reduction, Slow synchronization
Digital SLR	No
Power source type	Battery
Camera shutter speed	60 - 1/4000 s
Scene modes	Children, Close-up (macro), Dawn, Night, Night landscape, Night portrait, Party (indoor), Portrait, Sports
Image editing	Resizing, Rotating
Photo effects	Black&White, Skin tones
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Battery capacity	1200 mAh
Battery life (CIPA standard)	340 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 6.0 HD Edition SILKYPIX Developer Studio 3.1 SE Super Loilo Scope

Weight and Dimensions

Depth	75.8 mm
Width	124 mm
Height	89.6 mm
Weight	609 g
