Panasonic Lumix DMC-GH2 User Manual

VQT3A36
26
Preparation
Recording conditions by CIPA standard
•
CIPA is an abbreviation of [Camera & Imaging Products Association].
• Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on.
• Using a Panasonic SD Memory Card (2 GB).
• Using the supplied battery.
• Starting recording 30 seconds after the camera is turned on.
• Recording once every 30 seconds with full flash every second recording.
• Turning the camera off every 10 recordings and leaving it until the temperature of the battery
decreases.
The number of recordable pictures varies depending on the recording interval time.
If the recording interval time becomes longer, the number of recordable pictures
decreases. [For example, if you were to take one picture every two minutes, then the
number of pictures would be reduced to approximately one-quarter of the number
of pictures given above (based upon one picture taken every 30 seconds).]
∫ Recording motion pictures (when using the LCD monitor)
–
[AVCHD] (Recording with picture quality set to [FSH] ([ ]))
–[MOTION JPEG] (Recording with picture quality set to [HD] ([ ]))
• These times are for an ambient temperature of 23 oC (73.4 oF) and a humidity of 50%RH.
Please be aware that these times are approximate.
• Actual recordable time is the time available for recording when repeating actions such as
switching the power supply [ON]/[OFF], starting/stopping recording etc.
¢ Motion picture recorded continuously in [MOTION JPEG] is up to 2 GB. Only the maximum
recordable time for 2 GB is displayed on the screen.
When the 14–140 mm/F4.0–5.8 lens supplied in
DMC-GH2H is used
Continuous recordable time Approx. 110 min
Actual recordable time Approx. 65 min
When the 14–42 mm/F3.5–5.6 lens supplied in
DMC-GH2K is used
Continuous recordable time Approx. 120 min
Actual recordable time Approx. 70 min
When the 14–140 mm/F4.0–5.8 lens supplied in
DMC-GH2H is used
Continuous recordable time Approx. 120 min
¢
Actual recordable time Approx. 70 min
¢
When the 14–42 mm/F3.5–5.6 lens supplied in
DMC-GH2K is used
Continuous recordable time Approx. 130 min
¢
Actual recordable time Approx. 75 min
¢
DMC-GH2H&GH2K&GH2PP-VQT3A36_eng.book 26 ページ ２０１０年１０月１９日 火曜日 午前１１時３分

Panasonic Lumix DMC-GH2 Specifications

General

Megapixel	16.05 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	3264 x 2448, 3456 x 3456, 4608 x 3456, 4752 x 3168
Filter size	62 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 140 mm
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 250, 500, 640, 800, 1600, 2000, 6400, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Pre-flash, Red-eye reduction, Slow synchronization
Digital SLR	No
Power source type	Battery
Camera shutter speed	60 - 1/4000 s
Scene modes	Children, Close-up (macro), Dawn, Night, Night landscape, Night portrait, Party (indoor), Portrait, Sports
Image editing	Resizing, Rotating
Photo effects	Black&White, Skin tones
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Battery capacity	1200 mAh
Battery life (CIPA standard)	340 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 6.0 HD Edition SILKYPIX Developer Studio 3.1 SE Super Loilo Scope

Weight and Dimensions

Depth	75.8 mm
Width	124 mm
Height	89.6 mm
Weight	609 g
