Panasonic Lumix DMC-GH2 User Manual

VQT3A36
62
Basic
• To accurately calibrate the LCD Monitor, be sure to touch precisely at the designated locations.
• If you set a different language by mistake, select [~] from the menu icons to set the desired
language.
• [–. –] is displayed as the lens firmware when the lens is not mounted.
• The folder number is updated and the file number starts from 0001. (P165)
• A folder number between 100 and 999 can be assigned.
The folder number should be reset before it reaches 999. We recommend formatting the card
(P62) after saving the data on a PC or elsewhere.
• To reset the folder number to 100, format the card first and then use this function to reset the
file number.
A reset screen for the folder number will then appear. Select [YES] to reset the folder number.
• When the [REC] Mode settings are reset, data registered with [FACE RECOG.] will also be reset.
• When [SETUP]/[CUSTOM] menu settings are reset, the following settings are also reset. In
addition, [ROTATE DISP.] (P148) in [PLAYBACK] Mode menu is set to [ON].
– The birthday and name settings for [BABY1]/[BABY2] (P100) and [PET] (P101) in Scene Mode.
– The settings of [TRAVEL DATE] (P114) (departure date, return date, location)
– The [WORLD TIME] (P115) setting.
• The folder number and the clock setting are not changed.
• Use a battery with sufficient battery power or the AC adaptor (DMW-AC8PP; optional) and DC
coupler (DMW-DCC8; optional) when formatting. Do not turn the camera off during formatting.
• If the card has been formatted on a PC or other equipment, format it on the camera again.
• If the card cannot be formatted, please try another card before contacting your nearest Service Center.
[CALIBRATION]
Adjust the position of the touch panel if a different thing gets selected
from what you touched or touch operation does not respond.
1 Press [MENU/SET].
2 Touch the orange [ r ] mark displayed
on the screen in order with the stylus
pen (supplied) (5 places).
• A message is displayed once the
position is set.
3 Press [MENU/SET] to finish.
~ [LANGUAGE]
Set the language displayed on the screen.
[ENGLISH]/[FRANÇAIS]/[ESPAÑOL]/[PORTUGUÊS]
[VERSION DISP.]
This enables the firmware versions of the camera and lens to be checked.
v [NO.RESET]
Reset the file number of the next recording to 0001.
w [RESET]
The [REC] or [SETUP]/[CUSTOM] menu settings are reset to the
initial settings.
[FORMAT]
The card is formatted.
Formatting permanently deletes all data on your memory
card. Please be sure all pictures and motion pictures are
saved elsewhere before using this feature.
For Canadian assistance, please call:
1-800-99-LUMIX (1-800-995-8649) or
send e-mail to: lumixconcierge@ca.panasonic.com
For USA and Puerto Rico assistance, please call:
1-800-211-PANA(7262) or, contact us via the web at:
http://www.panasonic.com/contactinfo
DMC-GH2H&GH2K&GH2PP-VQT3A36_eng.book 62 ページ ２０１０年１０月１９日 火曜日 午前１１時３分

Panasonic Lumix DMC-GH2 Specifications

General

Megapixel	16.05 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	3264 x 2448, 3456 x 3456, 4608 x 3456, 4752 x 3168
Filter size	62 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 140 mm
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 250, 500, 640, 800, 1600, 2000, 6400, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Pre-flash, Red-eye reduction, Slow synchronization
Digital SLR	No
Power source type	Battery
Camera shutter speed	60 - 1/4000 s
Scene modes	Children, Close-up (macro), Dawn, Night, Night landscape, Night portrait, Party (indoor), Portrait, Sports
Image editing	Resizing, Rotating
Photo effects	Black&White, Skin tones
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 10 s
Motion JPEG frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Battery capacity	1200 mAh
Battery life (CIPA standard)	340 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Bundled software	PHOTOfunSTUDIO 6.0 HD Edition SILKYPIX Developer Studio 3.1 SE Super Loilo Scope

Weight and Dimensions

Depth	75.8 mm
Width	124 mm
Height	89.6 mm
Weight	609 g
