Panasonic Lumix DMC-LX100 Basic Operating Instructions

58
SQT0375 (ENG)
Advanced Recording Functions
Taking pictures using the flash (supplied)
Recording mode:
This section describes how to take a picture using the flash (supplied).
Attaching the flash
The hot shoe cover is already attached to the hot shoe at the time of purchase.
Attach the flash to the hot shoe after removing the hot shoe cover.
Removing the hot shoe cover
• Make sure that the Camera [ON/OFF] switch is set to [OFF].
1
Remove the hot shoe cover by pulling it in the
direction indicated by arrow
while pressing it in
the direction indicated by arrow
• Be sure to attach the hot shoe cover when the
hot shoe is not in use.
• Keep the hot shoe cover safely after removing it
so that you do not lose it. (→9)
Attaching the flash
1
Turn off the flash Hot shoe
Lock release button
Flash [ON/OFF] switch
2
Firmly insert the flash into the hot shoe of this unit
until it clicks
• Set the Camera [ON/OFF] switch to [ON] and turn
on the flash when you take a picture.
●
Do not carry the camera holding by the flash when the
flash is mounted on the camera.
■
Removing the flash
Turn off the camera and the flash
Press and hold the lock release button and pull the flash in the direction
indicated by the arrow to detach the flash
• When detaching the flash, do so slowly and carefully.
• Attach the hot shoe cover to the hot shoe of the camera.
• Store the detached flash in its soft case.

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
