6 VQT3H08 VQT3H08 7
Before use (Continued)
Always take a test shot first
Before important events when you will use the camera (at weddings, for example),
always take a test shot to make sure that pictures and sound record correctly.
No compensation for missed shots
We cannot compensate for missed shots if technical problems with the camera or card
prevent recording.
Carefully observe copyright laws
Unauthorized use of recordings which contain works with copyright for purposes other
than personal use is prohibited under copyright law. Recording of certain material may
be restricted even for the purpose of personal use.
Also refer to “Usage cautions and notes” (141)
About GPS
About the camera’s location name information
Before using the camera, read “User License Agreement for Location Name Data”. (145)
When [GPS Setting] is [ON], the GPS function works even if the camera’s power
is off.
Electromagnetic waves from the camera can affect instruments and meters. During
airplane takeoff and landing or in other restricted area, set [GPS Setting] to [OFF] or
, then turn the camera’s power off. (76)
When [GPS Setting] is [ON], power will drain from the battery even if the camera’s
power is OFF.
Recording location information
The names of recording locations and landmarks (such as buildings) are current as of
December 2010. These will not be updated.
Depending on the country or area, limited location name and landmark information
may be available.
Positioning
Positioning will take time in environments where it is difficult to receive the signals
from the GPS satellites. (75)
Even if GPS reception is good, it will take approximately 2 to 3 minutes
to successfully execute positioning under the following conditions; when
positioning is executed for the first time, or when positioning is executed after
the camera is turned off with the [GPS Setting] set to
and then turned on
again or when [GPS Setting] is set to [OFF].
Because the positions of the GPS satellites are constantly changing, depending on
the recording location and conditions, it may not be possible to position such satellites
accurately, or positioning discrepancy may occur.
When using in another country
GPS may not work in China or in the border regions of countries neighboring China.
(Current as of December 2010)
Some countries or regions may regulate the use of GPS or related technology.
Because this camera has a GPS function, before taking it into another country, check
with the embassy or your travel agency whether there are any restrictions on bringing
cameras with a GPS function.

Table of Contents

Other manuals for Panasonic Lumix DMC-TZ20

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TZ20 and is the answer not in the manual?

Panasonic Lumix DMC-TZ20 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeCMOS
Image stabilizerYes
Total megapixels15.1 MP
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom4 x
Optical zoom16 x
Combined zoom64 x
Extra/Smart zoom33.8 x
Focal length range4.3 - 68.8 mm
Maximum aperture number5.9
Minimum aperture number3.3
Number of aspheric elements3
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)464 mm
Minimum focal length (35mm film equiv)29 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞/2.0 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)1.0 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 200, 400, 800, 1600, 2000, 2250, 3200, 6400, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Flash modesAuto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 2.8 m
Flash range (wide)0.6 - 5 m
Video outAV
Digital SLRNo
Power source typeBattery
Video memory capacity29min. 59sec.
Scene modesBeach, Candlelight, Children, Fireworks, Night, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Underwater
Image editingResizing, Rotating, Trimming
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesAuto, Movie
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemExif 2.3
On Screen Display (OSD) languagesENG, ESP, FRE, ITA, JPN
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Internal memory18 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
Product colorBlack
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 6.1 HD Lite Edition / QuickTime / Adobe Reader / Super LoiLoScope
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Weight and Dimensions IconWeight and Dimensions
Depth33.4 mm
Width104.9 mm
Height57.6 mm
Weight197 g
Weight (including battery)219 g
