Panasonic Lumix DMC-TZ20 User Manual

102 VQT3H08 VQT3H08 103
Different playback methods [Playback Mode]
Playback Mode:
Recorded pictures can be played back in a variety of ways.
Press [MENU/SET]
Use cursor button to select [Playback Mode] menu and press
[MENU/SET]
Use cursor button to select the playback method and press
[MENU/SET]
●
When no card is inserted, pictures are played back from the built-in memory.
●
The [Playback Mode] automatically becomes [Normal Play] when the REC/PLAY switch
is set to and the power is turned on, or when switching from Recording Mode to
Playback Mode.
[Slide Show]
Automatically play pictures in order and to music. Recommended when viewing on TV
screen.
Use cursor button to select the playback method and press
[MENU/SET]
[All] Play all.
[Picture Only] Plays back still pictures.
[Video Only] Plays back motion pictures.
[3D Play] Plays back only 3D still pictures that were recorded in [3D Photo
Mode].
[GPS Area Play] Selects place name or landmark to play back pictures recorded in the
same place. (Use cursor button to select place name or landmark and
press [MENU/SET]).
[Travel] Play only pictures that were recorded with the [Travel Setup] or
[Location].
[Category
Selection]
Select category and playback still pictures only.
(Select category with cursor button and press [MENU/SET].) (→104)
[Favorite] Play back pictures set as [Favorite].
Use cursor button to set playback effects and press [MENU/
SET]
[Effect] (Select music and effects according to picture atmosphere)
[AUTO] (only available with [Category Selection] setting)/[NATURAL]/[SLOW]/[SWING]/
[URBAN]/[OFF]
∗
[Setup]
[Duration]
∗
[1 SEC.] / [2 SEC.] / [3 SEC.] / [5 SEC.] (Only available when [Effect] is
[OFF])
[Repeat] [ON]/[OFF]
[Sound]
[AUTO]: With still pictures, music will play back, and with motion pictures,
audio will play back.
[Music]: Music effect will play back.
[Audio]: Audio is played back from motion pictures.
[OFF]: Music and audio will not play back.
∗
If [Video Only] was selected in step , [Effect] is fixed at [OFF]. Also, the duration cannot be
set.
Select [Start] with cursor button and press [MENU/SET]
■
Operations during Slide Show
During motion picture/burst group playback During still picture playback
Pause/play
Previous
Next
Stop
Volume down
Volume up
Pause/play
(While paused)
Previous
(While paused)
Next
Stop
Volume down Volume up
●
When [URBAN] has been selected, the picture may appear in black and white as a
screen effect.
●
Part of [Effect] cannot be used when displaying pictures on television using an HDMI
mini cable (optional) or when displaying pictures recorded in portrait position.
●
Music effects cannot be added.

Panasonic Lumix DMC-TZ20 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	15.1 MP
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	4 x
Optical zoom	16 x
Combined zoom	64 x
Extra/Smart zoom	33.8 x
Focal length range	4.3 - 68.8 mm
Maximum aperture number	5.9
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	464 mm
Minimum focal length (35mm film equiv)	29 mm
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/2.0 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	1.0 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 2000, 2250, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.8 m
Flash range (wide)	0.6 - 5 m
Video out	AV
Digital SLR	No
Power source type	Battery
Video memory capacity	29min. 59sec.
Scene modes	Beach, Candlelight, Children, Fireworks, Night, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Underwater
Image editing	Resizing, Rotating, Trimming
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Auto, Movie
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	Exif 2.3
On Screen Display (OSD) languages	ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	M-JPEG
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Internal memory	18 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.1 HD Lite Edition / QuickTime / Adobe Reader / Super LoiLoScope
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s

Weight and Dimensions

Depth	33.4 mm
Width	104.9 mm
Height	57.6 mm
Weight	197 g
Weight (including battery)	219 g
