- 18 -
Preparation
Inserting and Removing the Card (optional)
• Check that this unit is turned off.
• We recommend using a Panasonic card.
1
Slide the release lever in the direction of the
arrow and open the card/battery door.
2
Push it securely all the way until you hear a
“click” while being careful about the
direction in which you insert it.
To remove the card, push the card until it
clicks, then pull the card out upright.
A: Do not touch the connection terminals of the card.
3
1: Close the card/battery door.
2: Slide the release lever in the direction of
the arrow.
• Turn the camera off and wait for the “LUMIX” display on the monitor to clear before removing the
card.
(Otherwise, this unit may no longer operate normally and the card itself may be damaged or the
recorded pictures may be lost.)
