26 VQT1Z93 VQT1Z93 27
See P.18 for the setting procedure in the SETUP menu.
Using SETUP menu
(Continued)
VIERA Link
Enable automatic linking
with other VIERA Link-
compatible devices,
and operability with a
VIERA remote control
when connecting via an
HDMI mini cable (sold
separately) (P.109).
OFF : Operations must be performed via the camera’s
own buttons.
ON: Operations may be performed via the remote control
of the VIERA Link-compatible device.
(Not all operations will be available.) Operability of
the camera’s own buttons will be limited.
Works when connected via an HDMI mini cable
(sold separately).
VERSION DISP.
Check the version of the
camera firmware.
Current version is
displayed.
FORMAT
Use when ‘BUILT-IN
MEMORY ERROR’
or ‘MEMORY CARD
ERROR’ appears, or
when formatting the built-
in memory or card.
When a card/built-in
memory is formatted,
the data cannot be
restored. Check the
content of the card/
built-in memory
carefully before
formatting.
YES/NO
This requires a sufficiently charged battery (P.13) or AC
adaptor (DMW-AC5E, optional).
(Only inserted card will be formatted if present; built-in
memory will be formatted if no card is inserted.)
Always format cards with this camera.
All picture data including protected pictures will be
deleted. (P.97)
Do not turn off power or perform other operations during
formatting.
Consult your nearest Service Centre if format cannot be
successfully completed.
Formatting the built-in memory may take several minutes.
LANGUAGE
Change display
language.
ENGLISH
/ DEUTSCH
(German) / FRANÇAIS
(French) /
ESPAÑOL (Spanish) / ITALIANO
(Italian) /
日本語
(Japanese)
Item Settings, notes
The ‘VIERA Link’ menu item is not available in the DMC-TZ6/DMC-TZ65.
Item Settings, notes
DEMO MODE
View demonstration of
functions.
JITTER, SUBJ. MOVE DEMO.: (Only during recording)
Extent of jitter and of subject movement are shown on
graph. (Estimate)
Movement detection
Jitter
Large Small Large
When the REC/PLAY switch is , a guidance message
is displayed that asks the user to switch to .
To stop Press display button (P.12).
Recording and zoom cannot be performed during demo.
Use the movement detection demo with objects with
contrasting colouring.
AUTO DEMO : View introductory slideshow
OFF/ON
To close Press ‘MENU/SET’
If the camera is left switched on while connected to the
AC adapter (DMW-AC5E, sold separately) and with no
card inserted, the demo will automatically begin whenever
no operations are performed for approx. 2 minutes.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-TZ6 and is the answer not in the manual?

Panasonic LUMIX DMC-TZ6 Specifications

General IconGeneral
Megapixel10.1 MP
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.5 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution3648 x 2736 pixels
Digital zoom4 x
Optical zoom12 x
Focal length range4.1 - 49.2 mm
Lens structure (elements/groups)10/8
InterfaceAV Output
Digital SLRNo
Camera shutter speed8 - 1/2000 s
Focal length (35mm film equivalent)25 - 300 mm
Focus adjustmentAuto
Auto focusing (AF) modescontinuous auto focus, multi point auto focus, selective auto focus, single auto focus, spot auto focus
Macro focusing range (tele)2.0 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Auto Mode focusing range (wide)0.5 - ∞ m
Internal memory40 MB
Compatible memory cardsmmc, sd
Motion JPEG frame rate30 fps
Maximum video resolution640 x 480 pixels
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
USB version2.0
Scene modesBacklight, beach, Candlelight, Children, Fireworks, Night, Night landscape, Night portrait, Panorama, party (indoor), Portrait, self-portrait, Sports, Sunset
Image editingresizing, trimming
White balanceauto, Cloudy, custom modes, daylight, Shade
Camera playbacksingle image, slide show, thumbnails
Self-timer delay2 s
Product colorBlack
Battery capacity895 mAh
Battery life (CIPA standard)320 shots
Bundled software- PHOTOfunSTUDIO v3.0 - ArcSoft (MediaImpression / Panorama Maker) - USB Driver - QuickTime
Flash modesauto, Red-eye reduction, Slow synchronization
Light meteringCentre-weighted, Spot
Weight and Dimensions IconWeight and Dimensions
Depth32.8 mm
Width103.3 mm
Height59.6 mm
Weight229 g
