Panasonic Lumix DMC-TZ60 Operating Instructions

Preparations
Names and Functions of Main Parts
VQT5E94- 12 -
1 Flash (→31, 85)
2 Self-timer indicator (→105) /
AF Assist Lamp (→149)
Illuminates when the self-timer is set or
when the Auto Focus is operated in dark
locations.
3 Control ring (→33)
Allows you to zoom and adjust settings
when recording.
4 Lens barrel
5 Lens
6 Speaker
7 Microphones (→31, 48)
8 Mode dial (→30)
Use this to select the Recording Mode.
9 Shutter button
10 Zoom lever (→80)
Use the lever to zoom in and enlarge a
distant subject.
11 Motion picture button (→48)
Record motion pictures.
12 Camera [ON/OFF] button
Use this to turn the camera on and off.
13 Tripod mount (→318)
Do not attach to a tripod with a 5.5 mm
(0.22 inch) or longer screw. Doing so
may damage this unit.
It may not be possible to attach certain
types of tripods properly.
14 Card/Battery door (→18, 24)
Open this door to insert and remove a
card or battery.
15 Release lever (→18, 24)
(Top)
(Bottom)
1 2 3 4 5
7 8 9 116 1210
13 14 15

Panasonic Lumix DMC-TZ60 Specifications

General

Sensor Type	CMOS
Effective Pixels	18.1 Megapixels
Optical Zoom	30x
Max Aperture	f/3.3 - 6.4
Display Size	3.0-inch
Connectivity	Wi-Fi, NFC
Sensor Size	1/2.3-inch
LCD Screen Resolution	920, 000 dots
GPS	Yes
Digital Zoom	4x
Dimensions	110.6 x 64.3 x 34.4 mm
Built-in Flash	Yes
Focal Length	4.3 - 129 mm
Image Stabilization	Optical
Viewfinder	Electronic Viewfinder
Video Resolution	1920 x 1080 (FHD)
ISO Sensitivity	100-6400
Battery	Lithium-Ion Battery Pack
Weight	240 g (with battery and SD card)
Shutter Speed	4 - 1/2000 sec
Battery Life	Approx. 300 pictures
