Focus / Zoom – Using AF
168
Registering the Adjusted Value
1 Select [ALL] or [ADJUST BY LENS] and then press [DISP.].
2 (When [ADJUST BY LENS] is selected) Register the lens.
• Press [DISP.] and select [Yes] to register.
• If the lens is already registered, the screen moves to the one in Step 3.
3 (When [ADJUST BY LENS] is selected) Select [Wide Adjustment] or [Tele
Adjustment].
• Press 34 to select, and then press or .
• When using a prime lens, [Adjustment] is displayed.
4 Adjust the focus point.
• Press 21 to adjust the focus point and then press or .
• You can also adjust by rotating , , or .
• The focus point is moved backward when adjusted with the [+] side. The focus
point is moved forward when adjusted with the [−] side.
5 Record and repeat Step 4 until the suitable focus point is reached.
• Check the set focus point in an image recorded with [AFC] of the [Focus/
Shutter Priority] set to [FOCUS] and with the focus mode set to [AFC].
([Focus/Shutter Priority]: 573)
