Panasonic MAC0105011C3 - Page 8

Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way
valve
L ; 2-way
valve
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas
side)
L ; (liquid
side)
Drain
Hose
Inner diameter mm 12 —
Length m 0.7 —
Power Cord Length
Number of core-wire
m 2.0
3 (1.0 mm
2
)
—
—
Dimensions Height inch (mm) 10 - 31/32 (279) 18 - 29/
32
Width inch (mm) 31 - 15/32 (799) 30 - 23/
32
Depth inch (mm) 7 - 27/32 (199) 9 - 21/32
(
Net Weight lb (kg) 20 (9.0) 71 (
32.0)
Compressor Type — Rotary (1
cylinder)
rolling
piston
Motor Type — Induction (
2
Rated Output W — 700
Air Circulation Type Cross-flow Fan
Propeller
Material AS + Glass Fiber 30% AES + Glass
Fiber
Motor Type Induction (4-poles) Induction (
6
Input W 32.2 - 34.5 65.8 -
57.5
Rate Output W 14 20
Fan Speed Low rpm Cooling; 930 - 820 —
Heating; 930 - 820
Medium rpm Cooling; 1,080 - 965 —
Heating; 1,080 - 965
High rpm Cooling; 1,275 - 1,210 —
Heating; 1,345 - 1,310
SuperHigh rpm Cooling; 1,345 - 1,310
—
Heating; 1,345 - 1,310
Heat Exchanger
Description
Evaporator
Condenser
Tube
material
Copper
Copper
Fin
material
Aluminium (Pre Coat) Aluminium (
Pre
Fin Type Slit Fin
Louver
Row / Stage (Plate fin configuration, forced
draft)
2 × 14 1 ×
18
FPI 18 19
Size (W × H × L) mm 614 × 294 × 25.4 856 ×
457.2
Refrigerant Control Device —
Capillary
Refrigeration Oil (c.c) — SUNISO
4GDID
ATMOS
M60
Refrigerant (R-22) g (oz) — 900 (
31.8)
Thermostat Electronic Control —
Protection Device — Overload
Protector
8
