Panasonic MC-CG917

- 18 -
Latch
Loquet
Dispositivo
de retentión
Tab
Languette
Pestaña
Slot
Fente
Ranura
Air Turbine and Caddy
TO ATTACH CADDY
➢ Align the tab on the wand with the
slot in the Air Turbine caddy.
➢ Press the caddy onto the upper
wand. The caddy will snap into
place
TO INSERT AIR TURBINE
➢ Place the front of the Air Turbine into
the caddy.
➢ Rotate the Air Turbine back until it
snaps into place.
TO REMOVE AIR TURBINE
➢ Press the latch and lift the Air
Turbine out of the caddy.
CREVI
CE
TOOL
FLOO
BRUS
COMBO
Combo Brush
Brosse combinée
Cepillo combinación
Floor Brush
Brosse à
planchers
Cepillo para pisos
Crevice Tool
Suceur plat
Herramienta
para hendiduras
Tool Storage (Inside)
Logement des
accessoires
Almacenamiento
para herramientas
Release Button
Loquet de
dégagement
Botón de liberation
Tool Storage
➢
Tools are stored on-board the
vacuum cleaner in the tool storage
area.
➢
To open, press cover release button
on the tool storage cover.
➢
Open cover to access tools as
needed (See USING TOOLS).
