Panasonic NA-128VB6WAE - Page 47

47
13.3.2. Washing Group Spare Parts List
Safety Ref. No. Part Name & Description Part No. Qty Remarks
103 REAR TUB GROUP AXW12A-37596 1
117 FRONT TUB AXW32G-26347 1
160 DRUM GROUP AXW22B-13470 1
102 MOTOR AXW401-16256 1
113 TUB SEAL AXW212-15077 1
101 DRIVEN PULLEY AXW502-00499 1
100 BELT AXW412-25178 1
122 COUNTERSUNK HEAD BOLT 828 TORX AXWSS1-07899 4
206 TUB ENTERANCE WITH BELLOW HOSE AXWEBH-87110 1
118 TUB BELLOWS SEAL AXW212-25995 1
126 HEXAGON HEAD BOLT 630 PT AXWSS3-15518 19
900 HEXAGON HEAD BOLT 1052 AXWSB1-23804 4
241 PLAIN WASHER 10.5402.5 AXW420-08965 4
810 PLAIN WASHER (SAFETY) AXWSW1-06960 4
105 SHOCK ABSORBER PIN-2 AXWSAP-25094 4
119 TUB GASKET CLIP AXW212-08555 1
120 FRONT CONCRETE WEIGHT AXW1231-9244 1
121 RESISTANCE GR AXWRG1-96002 1
999 NTC AXW1EV-35970 1
899 RESISTANCE WITHOUT NTC AXWRG1-16814 1
115 RESISTANCE FIXING WIRE AXWRFW-18738 1
104 SHOCK ABSORBER AXWSA1-11587 2
213 TUB EXIT BELLOWS GR(HOSE+BALL) AXW1250-7585 1
124 COUNTERSUNK HEAD BOLT M 829 AXWSB2-05142 1
700 TUB HANGER SPRING PART AXWTHS-19298 2
800 TUB SPRING AXW3441-5308 2
808 MUSHROOM HEAD SQUARE NECK BOLT
M 865
AXWSB3-03063 2
806 PLAIN WASHER 8.4283 AXWSW2-07454 2
811 UPPER CRT SUPPORT SHEETIRON PART AXWUCS-16379 2
812 HEX.NUT WITH FLANGE SERRATED M8 AXWXNF-06921 2
813 PLASTIC LIFTER AXW1PL-56336 3
112 UPPER CONCRETE WEIGHT AXW1231-0333 1
221 HANGER SPRING SHEETIRON PLS. AXW1HS-16727 2
816 RESISTANCE PROTECTION FOIL-1-C AXW1PF-07557 1
817 SCREW 3,57PAN HEAD WITH COLAR
CROSS RE.
AXWSS4-15637 2
