Operating & Installation
Instructions
Washing Machine
(Household Use)
Model No.
NA-128VG6
Thank you for purchasing this product.
- Read these instructions carefully for optimum
performance and safety before use.
- Keep this manual for future reference.
Contents
SAFETY PRECAUTIONS
4
Before Using
8
Washing
14
Optional Functions
22
Maintenance
27
Troubleshooting
30
Installation / Others
34
W9901-3MZ00
NA-128VG6_EN(HK).indd 1 2017-10-12 17:29:25

Table of Contents

Questions and Answers

  • S
    stephensmaureenAug 20, 2025
    What to do if the door of my Panasonic Washer doesn't open?
    • J
      jenniferbrownAug 20, 2025
      The door may not open for several reasons. It could be locked because an operation is in progress. The Child Lock may be activated. The temperature inside the drum may be very high, or the water level might be too high. In the latter two cases, switch the appliance off and on again, then run the Spin operation. If you switch off the appliance or there is a power cut while the door is locked, it remains locked until the power is turned on again.
  • A
    alexa85Aug 22, 2025
    Why is there no water going into my Panasonic NA-128VG6?
    • B
      ballardbrendaAug 22, 2025
      There might be several reasons why water isn't entering the appliance. The tap may be turned off, the water supply could be disrupted, or the water supply hose may be frozen.
  • E
    evan48Aug 25, 2025
    What to do if the water supply to my Panasonic Washer is disrupted?
    • T
      Terry JordanAug 25, 2025
      If the water supply is disrupted, disconnect the water supply hose, run the tap until the water is no longer discoloured, and then reconnect the water supply hose.
  • T
    Tamara BonillaAug 26, 2025
    Why is water draining out during a wash cycle in my Panasonic NA-128VG6 Washer?
    • T
      tkleinAug 26, 2025
      If there's excess foam, the washer drains water and adds fresh water to remove it. This is the foam detection function. Also, even if water is directly supplied to the drum, it may drain away without building up.
  • D
    David LopezAug 28, 2025
    Why are the buttons on my Panasonic NA-128VG6 not working?
    • J
      John FoxAug 28, 2025
      The buttons may not work because settings cannot be changed while a wash cycle is in progress; only the spin speed and “Extra Rinse” settings can be adjusted when the process is paused. Also, the Child Lock may be activated.
  • M
    mflemingAug 29, 2025
    Why is there an unusual noise or vibration coming from my Panasonic NA-128VG6 Washer?
    • R
      Rachel LoveAug 30, 2025
      An unusual noise or vibration could be caused by a metal item inside the drum or because the anchor bolts have not been removed.
  • M
    michaela39Aug 31, 2025
    What happens if there is a power cut during operation of my Panasonic NA-128VG6 Washer?
    • J
      John GomezAug 31, 2025
      If there is a power cut during operation, the appliance will automatically resume from where it stopped once the power is restored.
  • T
    Tina BishopSep 2, 2025
    What should I do if the circuit breaker trips during operation of my Panasonic NA-128VG6 Washer?
    • J
      Jessica ScottSep 2, 2025
      If the circuit breaker trips, identify and resolve the cause, then reset the breaker. The washer will automatically resume operation from where it stopped when the power is recovered.
  • S
    Samuel FloresSep 4, 2025
    Why is there not enough or too much foam in my Panasonic Washer?
    • P
      Priscilla BrewerSep 4, 2025
      The amount of foam can vary depending on the water's temperature, level, and softness. Also, powdered detergent may have been put directly into the drum instead of the detergent drawer.
  • K
    kevinchristensenSep 6, 2025
    Why does rinsing begin before the spin process finishes in my Panasonic Washer?
    • S
      sbradySep 6, 2025
      Rinsing might start early if the appliance detects an unbalanced load and begins rinsing to correct it. Also, if excess foam remains after washing, the water is drained and refilled to wash the foam away.

Summary

Safety Precautions

Preventing Electric Shock and Fire Hazards

Guidelines to prevent electric shock, overheating, combustion, and fire risks.

Correct Use and Leak Prevention

Instructions for proper appliance usage and measures to prevent water leaks.

Avoiding Injury and Appliance Damage

Precautions to prevent personal injury and damage to the appliance or laundry.

Washing Machine Overview

Key Appliance Components

Identification and labeling of the main parts of the washing machine.

Included Accessories

List and identification of accessories provided with the washing machine.

Before Washing

Initial Checks and Laundry Preparation

Steps for pre-wash checks, laundry preparation, and sorting clothes by type.

Loading Laundry Correctly

Guidelines for loading clothes into the drum to prevent damage or malfunction.

Control Panel and Display

Control Panel Layout and Functions

Explanation of the control panel buttons, dial, and their functions.

Understanding Display Indicators

Description of various symbols and indicators shown on the washing machine's digital display.

Detergent Usage

Detergent, Softener, and Additives

Guidance on using detergent, fabric softener, bleach, and stain removers.

Detergent Types and Best Practices

Advice on low-foam detergents, water softeners, and prewash detergent.

Washing Operations

Basic Washing Method Steps

A step-by-step guide for performing a standard wash cycle.

Adjusting Wash Settings

How to modify temperature, spin speed, preset timer, and water level.

Utilizing Optional Wash Functions

Instructions for selecting and using additional wash functions like Mode, Prewash, Extra Rinse.

Programme Guide

Programme List Overview

A summary of wash programmes with descriptions, load capacity, and cycle times.

Detailed Programme Settings

Specific settings for water temperature, level, and spin speed for each programme.

Washing Tips

Programme-Specific Advice

Tips for 'Wool'/'Delicates' programmes, 'Bedding' programme, drying, and shrinkage.

Active Foam Function Explanation

Details on how the 'Active Foam' feature operates with specific wash cycles.

Customizing Wash Settings

Adjusting Water Temperature and Level

Instructions for changing the washing water temperature and amount.

Adjusting Spin Speed and Preset Time

How to modify spin speed for drying and set the programme's end time.

Advanced Washing Options

Selecting Wash Processes (Mode)

How to choose combinations of wash, rinse, and spin processes.

Prewash and Extra Rinse Options

Using Prewash for heavily soiled items and Extra Rinse for thorough washing.

Appliance Settings Management

Buzzer and Active Foam Control

How to disable the end-of-programme buzzer and the 'Active Foam' function.

Child Lock Feature Activation

Instructions for locking and unlocking the control panel and door.

Maintenance Procedures

Filter and Hose Care

Cleaning the water supply filter and handling frozen water supply hoses.

Drum and Detergent Drawer Cleaning

Methods for cleaning the drum, detergent drawer, and appliance exterior.

Drain Filter Cleaning

Procedure for removing lint from the drain filter to ensure proper drainage.

Troubleshooting Guide

Common Appliance Issues

Solutions for problems like unresponsive buttons, door not opening, and unusual odors.

Wash Cycle Problems

Troubleshooting for no water intake, increased water usage, or water draining during wash.

Rinse;Spin and Foam Issues

Addressing water supply during rinse, spin anomalies, and foam level problems.

Other Troubleshooting Scenarios

Solutions for noise, power interruptions, circuit breaker trips, and display issues.

Error Code Reference

Understanding Error Codes

Explanation of error codes (U11-U14, H) and recommended corrective actions.

Installation Location and Requirements

Choosing the Right Installation Spot

Guidelines on suitable and unsuitable locations for installing the washing machine.

Installation Space Requirements

Required clearance dimensions for proper installation, including side and rear spacing.

Moving and Installing the Appliance

Transporting and Bottom Plate Installation

Instructions for safely carrying the appliance and installing the bottom plate.

Removing Shipping Bolts and Levelling

Steps to remove transit bolts and level the appliance using adjustable feet.

Connecting Hoses and Water Supply

Hose Connection Diagrams

Illustrations showing correct hose connections for right and left side installations.

Water and Drain Hose Setup

Detailed steps for connecting the water supply hose and drain hose to fixtures.

Post-Installation Checks

Appliance Parts Checklist

A checklist to verify all parts are correctly installed and secured before operation.

Test Run Procedures

Steps for conducting a test run to check for leaks, noise, and error displays.

Performance Data

Energy and Water Usage

Table showing power consumption, water usage, and time for different wash programmes.

Technical Specifications

Appliance Specifications

Key technical details including model number, voltage, dimensions, and weight.

Power Supply Check

Guidance on verifying the appliance's power requirements match the household supply.

Panasonic NA-128VG6 Specifications

General IconGeneral
Capacity8 kg
Energy RatingA+++
Spin Speed1200 RPM
Weight72 kg
ColorWhite
Wash Programs15
Child LockYes
Voltage220-240 V
Frequency50 Hz
TypeFront Load Washer
