Panasonic NA-147VB2

37
Water-drain hose
Points to remember:
Do not twist, pull out or bend the drain hose.
Your washing machine should be no more than 100cm from the drain outlet.
Draining to a sink or wash-basin:
●Securethedrainhoseinposition,soitcan’tdropoutofthebasin.
●Don’tblockthebasin’sdrainoutlet,andmakesurethedrainage
through it is sufficient.
●Don’tletthetipofthedrainhosedipintothedrainedwater,asthis
can cause the water to flow back into the washing machine.
Draining to a wash-basin Draining to a drain hose
Elbow
Connecting to the power supply
The name plate tells you the rated power your washing machine
needs. Check that your power supply specifications match these.
Name plate
Installation
Instructions
Water-supply hose Water-drain hose Connecting to the power supply
