Panasonic NA-F100A9

26
Installation (continued)
CAUTION
z Tighten the nut firmly.
z Do not twist, squash, modify or cut
the hose.
Connect the water supply hose
 Screw type
1
2
3
4
5
Thread:
Approx.
4 mm
Loosen
1
2
Tighten
Tighten securely
(To prevent water
leakage)
1
2
3
 Joint type
Joint type Screw type
Check that the
elbow is not loose.
