Panasonic NA-F100G3

- 7 -
3.1 Function Control with Fuzzy sensor
Clothes quantity checking, wash level indication and detergent consumption indication with Fuzzy Logic
System.
1. Check clothes quantity and specify the amount of
detergent
1. Wash timer and spin timer with checked clothes quantity
2. Additional wash timer and spin timer as temperature
increases
<Motor status>
Turn Switch “ON”
Press “Start” button
1. Check clothes quantity
2. Check ambient
temperature
A. Check clothes
quantity
B. Control wash time
C. Control spin time
Supply water to a proper
level
WASH
RINSE
SPIN
Switch will automatically
cut the power current
“OFF”
Spin Timer +0 min. +1 min. +2 min. +0 min.
Wash Timer +0 min. +2 min. +3 min. -1 min.
External temp. 25°C 15°C 5°C 30°C
High
3.0 Kg and more
Medium
1.2 Kg~3.0 Kg
Low
0 Kg~1.2 Kg
Wash Timer 12 min. 12 min. 9 min.
Spin Timer 6 min. 6 min. 5 min.
2. Temperature checking
Check temperature in the atmosphere when the machine
starts. In case of low temperature, wash timer and spin timer are
extended automatically so that washed clothes are as clean as
washing in high temperature.
<Checking Method>
Check cross pressure at the
capacitor while the Pulsator operates
without water.
Rotate clockwise
stop
Rotate
anti-clockwize
stop
Rotate clockwise
stop
Rotate
anti-clockwize
stop
Rotate clockwise
stop
Rotate
anti-clockwize
stop
NA-F80B3 / F80H3 / F90B3 / F90H3 / F90G3 /
F1003B / F1003H / F1103G / F100B3 / F100H3 / F100G3
