Panasonic NA-FS85G3 - PS and SF Switch Replacement

‐14‐
7. Disassembly Instructions
7.4 The PS SWITCH, SF SWITCH replacement
2.Remove2screwsmountingcontrolpanel,openlid,thenpulloutthepanel.
• PSSWITCHreplacement.
a. Removeleadwireconnector.
b. RemoveSUBHOSEA,thenremovePSSWITCH.
• SFSWITCHreplacement.
a. Removeleadwireconnector.
b. Remove2screwsmountingtheSFSWITCH.
1.Removethe2screwsmountingthePANELA,thenremovethePANELA.
PSSwitch
SubHoseA
LeadWireConnector
SFSwitch
