7. Disassembly Instructions
7.5 The FEED VALVE replacement
Repeatstep1&2inpreviouspage,toremovePANELAandcontrolpanelassembly.
• FEEDVALVE(cold)replacement
a. RemoveLEADWIRECONNECTOR.
b. Remove2screwsmountingtheFEEDVALVE.
c. RemoveFEEDVALVE.
• FEEDVALVE(hot)replacement
a. TakeDETERGENTCASEBout.
b. RemoveLEADWIRECONNECTOR.
c. Remove3screwsmountingthe
DETERGENTCASEAU.
d. PullDETERGENTCASEAUup.
e. Remove2screwsmountingtheFEED
VALVE.
f. RemoveFEEDVAL VE.
Connector
Screw
