- 13 -
NC-BH30P, BH40P
4x8 Deltite screw
Motorized pump
Communicating bushing
Water pipe packing A
Water pipe
comp.
Container
comp.
DISASSEMBLY-3
DISASSEMBLY-4
Water pipe comp.
3.5x12 lock head
self-tapping
screws
Case of A comp.
Lead wire E comp.
3.3. Motorized Pump
1. Remove one holding screw for motorized pump.
2. Remove the communicating bushing from the water
pipe packing A and container comp.
3.4. Water Pipe Comp.
1. Remove water pipe comp.
2. Remove case A comp. after removing 2 screws fi xing
case of A comp.
NC-BH40-30-22.indd 13NC-BH40-30-22.indd 13 14-08-07 16:48:0214-08-07 16:48:02
