6.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00205H00AP CAUTION LABEL 1 APH
1 F00067600CP CAUTION LABEL 1 CPH
2 F00336Z20AP FUSE LABEL 1
3 F110D6Z00SAP CABINET BODY(U) 1 SD297S APH
3 F110D6Z00SCP CABINET BODY(U) 1 SD297S CPH
3 F110D8Q00BAP CABINET BODY(U) 1 SD277S APH/CPH,SD277B APH/CPH,SA247S CPH
3 F110D8Q00HAP CABINET BODY(U) 1 SD277W APH/CPH,P295WFX CPH, S255WFX CPH,S245WFX CPH
4 F100D6Z00AP BASE PLATE (U) 1 SD297S APH/CPH,P295WFX CPH
4 F100D6Z80AP BASE PLATE (U) 1 EXCEPT SD297S APH/CPH & P295WFX CPH
5 F201A6F10AP OVEN(U) 1
6 F20115H00AP COVER 1
7 F21314Y00XN PULLY SHAFT 1
8 F290D5Q00AP ROLLER RING(U) 1
10 E393C6Z00AP DOOR HOOK (U) 1 APH
10 E393C6Z00CP DOOR HOOK (U) 1 CPH
14 F40016Z00AP FAN MOTOR A 1 FOR INVERTER (U) COOLING
15 F40085H00AP FAN BLADE 1 FOR INVERTER (U) COOLING
16 F40256Z80AP ORIFICE 1
17 F401W6Z00AP BLOWER MOTOR (U) 1 SD297S APH/CPH,SD277 APH/CPH,P295WFX CPH
17 F401W6Z60AP BLOWER MOTOR (U) 1 SA247S CPH,S255WFX CPH,S245WFX CPH
18 F42486Z00AP FAN CASE C 1
20 F42505H00AP SIROCCO FAN C 1
21 F42676Z80AP FAN MOTOR B 1 FOR MAGNETRON COOLING
22 F601L6F00AP SENSOR (BU) 1 SD297S APH/CPH,SD277 APH/CPH,P295WFX CPH
23 F40246Z00AP EXHAUST GUIDE A 1
24 F44775H00AP EXHAUST GUIDE 1
25 F20025H00AP RACK SUPPORT 4
26 F65856Z00AP INVERTER BRACKET 1
27 F62386Z00AP WASHER 1
28 F62386F00AP WASHER 1
32 F100T5H00APG BACK PLATE(BU) 1
33 F400B6Z00AP FILTER (U) 2
34 F400K5H00APG EXHAUST ADAPTER 1
35 F63175H00SAP LAMP HOLDER 1 SD297S APH
35 F63176F00SAP LAMP HOLDER 1 SD297S CPH
35 F63175H10BAP LAMP HOLDER 1 SD277S APH/CPH,SD277B APH/CPH,SA247S CPH
35 F63175H10HAP LAMP HOLDER 1 SD277W APH/CPH,P295WFX CPH, S255WFX CPH,S245WFX CPH
36 F64375H00AP GLASS PLATE 1
37 F41576Z00APG FAN INSTALLATION PLATE 2
38 F42176Z00APG COVER PLATE 1
39 F42205H00APG COVER PLATE B 1
40 F607V6Z00APG LAMP COVER (U) 1
41 F61846Z00AP GROUNDING PLATE 1
42 F60405H00AP LAMP MEMBRANE 1
43 F61446Z00AP STIRRER MOTOR 1
44 F20155H00AP STIRRER 1
45 F20165H00AP ANTENNA SUPPORT 1
46 F60305H00AP INCANDESCENT LAMP 1
47 F60305H00AP INCANDESCENT LAMP 2 EXCEPT SD297S APH/CPH & P295WFX CPH
48 F61525H00AP SOCKET 1
49 F61525H00AP SOCKET 2 EXCEPT SD297S APH/CPH & P295WFX CPH
50 F67536Z00AP HALOGEN LAMP 2 SD297S APH/CPH,P295WFX CPH
51 F61456F20AP THERMAL CUTOUT 1
13
NN-SD297S / NN-SD277S / NN-SD277B / NN-SD277W / NN-SA247S / NN-P295WFX / NN-S255WFX / NN-S245WFX
