7.5. PARTS LIST
7.5.1. NN-SD297S APH/CPH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C110 ECEA1EKS101I AL CHEM CAPACITOR 1 100µF/25V
C111 ECQV1H474JL2 CAPACITOR 1 0.47µF/50V
C10 AECETK1V102B AL CHEM CAPACITOR 1 1000µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP A2BB00000150 VACUUM FLUORESCENCE DISPLAY 1
DISP HOLDER F66176Z00AP LCD HOLDER 1
F64578P00AP DIFFUSION SHEET 1
D40,D41,D220-D222 MA2C19600E DIODE 5
D10-D13,D110,D111 B0EAKT000025 DIODE 6
D224,D500,D502 MA2C700A0F DIODE 3
D130-D133 AE3294UBCA7 LED 4
IC1 MN101C88ADA L.S.I. 1
IC10 C0CAADG00060 IC 1
IC25 B3PAC0000060 IC 1
IC220 B1HBGFF00007 IC 1
IC350 C0EBH0000264 IC 1
IC501 C0ABBA000230 IC 1
IC550 C0CAALG00023 IC 1
Q130 B1BAAJ000003 TRANSISTOR 1
D25 D4EAY271A036 ZENER RESISTOR 1 270V
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V (CPH)
RY1 K6B1AZA00005 POWER RELAY 1 18V
RY2-RY8 K6B1AZA00011 POWER RELAY 7
RY9 K6B1CZA00004 POWER RELAY 1
T10 G4C4AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
RE80,RE81 EVEJ1HF2224B REVOLVING ENCODER 2
SW40-SW47,SW49-SW56 EVQ11L05R SWITCH 16
ZD110 B0BA3R500006 ZENER DIODE 1
ZD130,ZD220 B0BA01100004 ZENER DIODE 2
ZD500 B0BA01400009 ZENER DIODE 1
7.5.2. NN-P295WFX CPH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C110 ECEA1EKS101I AL CHEM CAPACITOR 1 100µF/25V
C111 ECQV1H474JL2 CAPACITOR 1 0.47µF/50V
C10 AECETK1V102B AL CHEM CAPACITOR 1 1000µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP A2BB00000150 VACUUM FLUORESCENCE DISPLAY 1
DISP HOLDER F66176Z00AP LCD HOLDER 1
D41,D220-D223 MA2C19600E DIODE 5
D10-D13,D110,D111 B0EAKT000025 DIODE 6
D224,D500,D502 MA2C700A0F DIODE 3
IC1 MN101C88ADF L.S.I. 1
IC10 C0CAADG00060 IC 1
IC25 B3PAC0000060 IC 1
IC220 B1HBGFF00007 IC 1
IC350 C0EBH0000264 IC 1
IC501 C0ABBA000230 IC 1
IC550 C0CAALG00023 IC 1
D25 D4EAY271A036 ZENER RESISTOR 1 270V
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V (CPH)
RY1 K6B1AZA00005 POWER RELAY 1 18V
RY2-RY8 K6B1AZA00011 POWER RELAY 7
RY9 K6B1CZA00004 POWER RELAY 1
T10 G4C4AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
SW1-SW4,SW6-SW8,SW11-SW35 EVQ11L05R SWITCH 32
ZD110 B0BA3R500006 ZENER DIODE 1
ZD220 B0BA01100004 ZENER DIODE 1
ZD500 B0BA01400009 ZENER DIODE 1
