7.5.3. NN-SD277* APH/CPH,S255WFX CPH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C110 ECEA1EKS101I AL CHEM CAPACITOR 1 100µF/25V
C111 ECQV1H474JL2 CAPACITOR 1 0.47µF/50V
C10 AECETK1V102B AL CHEM CAPACITOR 1 1000µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP A2BB00000150 VACUUM FLUORESCENCE DISPLAY 1
DISP HOLDER F66176Z00AP LCD HOLDER 1
D41,D220-D223 MA2C19600E DIODE 5
D10-D13,D110,D111 B0EAKT000025 DIODE 6
D224 MA2C700A0F DIODE 1
D500,D502 MA2C700A0F DIODE 2 SD277* APH/CPH
IC1 MN101C88ADE L.S.I. 1 SD277* APH/CPH
IC1 MN101C88ADF L.S.I. 1 S255WFX CPH
IC10 C0CAADG00060 IC 1
IC25 B3PAC0000060 IC 1
IC220 B1HBGFF00007 IC 1
IC350 C0EBH0000264 IC 1
IC501 C0ABBA000230 IC 1 SD277* APH/CPH
IC550 C0CAALG00023 IC 1 SD277* APH/CPH
D25 D4EAY271A036 ZENER RESISTOR 1 270V
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V (CPH)
RY1 K6B1AZA00005 POWER RELAY 1 18V
RY2-RY7 K6B1AZA00011 POWER RELAY 6
RY9 K6B1CZA00004 POWER RELAY 1 SD277* APH/CPH
T10 G4C4AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
RE80 EVEJ1HF2224B REVOLVING ENCODER 1 SD277* APH/CPH
VZ490 D3BB6103A006 VARISTOR 1 S255WFX CPH
ZD110 B0BA3R500006 ZENER DIODE 1
ZD220 B0BA01100004 ZENER DIODE 1
ZD500 B0BA01400009 ZENER DIODE 1 SD277* APH/CPH
7.5.4. NN-SA247S CPH,S245WFX CPH
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C584 AECETS1C100B AL CHEM CAPACITOR 1 10µF/16V
C10 AECETK1V471B AL CHEM CAPACITOR 1 470µF/35V
CX320 EFOEC8004A4 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AAAFD00025 VACUUM FLUORESCENCE DISPLAY 1
DISP HOLDER F66175E40AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D40,D41,D220,D221,D584 MA2C19600E DIODE 5
D10-D13 B0EAKT000025 DIODE 4
D585 MA2C700A0F DIODE 1
IC1 MN101C54CHP L.S.I. 1
IC10 C0CAADG00060 IC 1
IC25 B3PAC0000060 IC 1
IC220 B1HBGFF00007 IC 1
Q180 B1BAAJ000003 TRANSISTOR 1
D25 D4EAY271A036 ZENER RESISTOR 1 270V
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V
RY1 K6B1AZA00005 POWER RELAY 1 18V
RY2-RY7 K6B1AZA00011 POWER RELAY 6
T10 G4C4AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
VZ490 D3BB6103A006 VARISTOR 1
31
NN-SD297S / NN-SD277S / NN-SD277B / NN-SD277W / NN-SA247S / NN-P295WFX / NN-S255WFX / NN-S245WFX
05/07
S-8Q0, S-8Q1
S-8Q5, S-8Q6
S-8Q9
Printed in China
