Panasonic NV-DS37B - Page 39

Ref. No. Part No. Part Name & Description Remarks
VZ4501 VRT0158 TRANSIENT/SURGE ABSORBER D4ED12710002
VZ4502 VRT0158 TRANSIENT/SURGE ABSORBER D4ED12710002
VZ4503 VRT0158 TRANSIENT/SURGE ABSORBER D4ED12710002
VZ4902 VRT0158 TRANSIENT/SURGE ABSORBER D4ED12710002
MISCELLANEOUS
. VSC5209 MIC SHIELD PLATE
. VSC5231 JACK SHIELD PLATE
. VGQ6135 IR HOLDER
. VWJ1468 FRONT FPC
VEP28284A EVF C.B.A. (RTL)
C802 ECUM1C105KBN C.CAPACITOR CH 16V 1U
D801 B3AFB0000016 LED (WHITE)
D802 B3AFB0000016 LED (WHITE)
D803 02DZ6.2YTPH3 DIODE B0BC6R100014
D804 MA133 DIODE
FP802 VJS3931B021 CONNECTOR (FEMALE) 21P
FP803 K1MN22B00062 CONNECTOR
Q801 XP4501 TRANSISTOR-TRANSISTOR
R801 ERJ3GEYJ472 M.RESISTOR CH 1/16W 4.7K
R803 ERJ3RED470 M.RESISTOR CH 1/16W 47
R804 ERJ3RED470 M.RESISTOR CH 1/16W 47
R805 ERJ3GEYJ103 M.RESISTOR CH 1/16W 10K
VEP26254A MONITOR C.B.A. (RTL)
C903 F3F0J1060005 TANTALUM CAPACITOR
C906 ECUX1E471KBQ C.CAPACITOR CH 25V 470P
C907 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C908 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C909 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C910 ECUX1A104KBQ C.CAPACITOR CH 10V 0.1U
C911 ECUX1E471KBQ C.CAPACITOR CH 25V 470P
C913 ECUX1E471KBQ C.CAPACITOR CH 25V 470P
C916 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C917 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C918 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C921 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C923 ECUM1C106VB C.CAPACITOR CH 16V 10U
C927 ECUM1E104KBN C.CAPACITOR CH 25V 0.1U
C929 ECUX1E152KBQ C.CAPACITOR CH 25V 1500P
C931 ECUM1A105KBN C.CAPACITOR CH 10V 1U
C932 ECUM1E105KBM C.CAPACITOR CH 25V 1U
C934 ECUM1C105KBN C.CAPACITOR CH 16V 1U
C935 ECUM1C106VB C.CAPACITOR CH 16V 10U
C937 ECUX1A104KBQ C.CAPACITOR CH 10V 0.1U
C938 ECUX1H101JCQ C.CAPACITOR CH 50V 100P
C939 ECUX1H331GCV C.CAPACITOR CH 50V 330P
