Panasonic NV-DS37B - Page 40

Ref. No. Part No. Part Name & Description Remarks
C940 ECUX1H560JCQ C.CAPACITOR CH 50V 56P
C941 ECUX1H100CCQ C.CAPACITOR CH 50V 10P
C942 ECUM1C474KBN C.CAPACITOR CH 16V 0.47U
C943 ECUX1A224KBV C.CAPACITOR CH 10V 0.22U
C944 ECUX1A224KBV C.CAPACITOR CH 10V 0.22U
C945 ECUX1E332KBQ C.CAPACITOR CH 25V 3300P
C946 ECUM1C106VB C.CAPACITOR CH 16V 10U
C947 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U
C948 ECUX1C104KBV C.CAPACITOR CH 16V 0.1U
C950 ECUM1C105KBN C.CAPACITOR CH 16V 1U
C952 ECUM1E104KBN C.CAPACITOR CH 25V 0.1U
C953 ECUX1C103KBQ C.CAPACITOR CH 16V 0.01U
D903 DAP222 DIODE
D904 MA159A DIODE
D905 MA6S121 DIODE
D906 MA111 DIODE
D908 02DZ6.2YTPH3 DIODE B0BC6R100014
FP901 VJS3320B024 CONNECTOR (FEMALE) 24P K1MN24B00036
FP903 K1MN25B00033 CONNECTOR
IC901 AN2540FHQ-V IC
IC902 TC4W53FU IC
IC908 SN74LV04APW IC C0JBAB000247
IC991 DN8797MS HALL IC
L901 VLQ0807K100 COIL 10UH G1C100K00024
L905 VLQ0807K100 COIL 10UH G1C100K00024
Q901 HN1C01FUYR TRANSISTOR B1HBCFA00001
Q902 2SK2159 TRANSISTOR
Q903 HN1B04FUGRR TRANSISTOR B1HFCFE00001
Q905 HN1B04FUGRR TRANSISTOR B1HFCFE00001
Q906 2SA1832FY TRANSISTOR
QR901 DTC144TH DIGITAL TRANSISTOR
QR902 DTC114YH DIGITAL TRANSISTOR
QR903 DTC114YH DIGITAL TRANSISTOR
QR904 DTC144TH DIGITAL TRANSISTOR
QR905 UN9212 TRANSISTOR-RESISTOR
R901 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0
R903 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K
R904 ERJ3RBD622 M.RESISTOR CH 1/16W 6.2K
R907 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0
R908 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100
R909 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100
R910 ERJ3GEYJ101 M.RESISTOR CH 1/16W 100
R912 ERJ3GEYJ334 M.RESISTOR CH 1/16W 330K
R914 ERJ3GEYJ104 M.RESISTOR CH 1/16W 100K
R915 ERJ3RBD333 M.RESISTOR CH 1/16W 33K
R917 ERJ3RBD103 M.RESISTOR CH 1/16W 10K
R918 ERJ3GEYJ272 M.RESISTOR CH 1/16W 2.7K
R919 ERJ6GEY0R00 M.RESISTOR CH 1/10W 0
R920 ERJ3GEY0R00 M.RESISTOR CH 1/16W 0
R921 ERJ3GEYJ153 M.RESISTOR CH 1/16W 15K
40
