Panasonic NV-DS37B - Page 43

Ref. No. Part No. Part Name & Description Remarks
R988 ERJ3GEYJ102 M.RESISTOR CH 1/16W 1K
T901 ETJ09K59AZ CHIP TRANSFORMER
T902 EFTU21R203 TRANSFORMER
VEP22308A CCD FLEX.CARD C.B.A. (RTL)
C291 ECUM1C105KBN C.CAPACITOR CH 16V 1U
C295 ECUM1E104KBN C.CAPACITOR CH 25V 0.1U
D291 MA143 DIODE
PS291 K1KB14A00039 CONNECTOR(FEMALE) 14P
Q291 2SC3930 CHIP TRANSISTOR
R292 ERJ6GEYJ822 M.RESISTOR CH 1/10W 8.2K
MISCELLANEOUS
. VJB22308 CCD FLEX. CARD
VEK9290 LENS FLEX.CARD C.B.A. (RTL)
MISCELLANEOUS
. HT-120B HALL SENSOR
. VSP1083 DETECTION SWITCH K0L1BA000015
. VJB20865 LENS FLEX. CARD
43
