Close the Cassette
Compartment Cover
by pressing the
[LOCK] Button.
0:00.00 0:00.00
Look into the Viewfinder and turn the Eyepiece
Corrector Ring until the indications in the
Viewfinder are clear and easy to read.
The tilting range of the Viewfinder is 75°.
To return the Viewfinder to its original horizontal
position, turn it all the way down until it locks with
a click.
Basic Operations i
Remarks, etc.
When you turn on the Movie Camera while a video
cassette is already inside, it is automatically put in the
Recording Pause Mode. (p. 19)
@ Ejecting the Video Cassette
After you have stopped recording, slide the [EJECT 4]
Lever to the left. The Cassette Compartment Cover
opens after a few seconds and you can then take out
the video cassette.
lt is not possible to take out the video cassette during
recording.
eDo not repeatedly insert and take out the video
cassette. This could cause the tape to become loose
and damaged.
®Do not hold the Movie Camera by the Viewfinder or
apply any pressure on it.
@Never aim the Movie Camera with its Viewfinder or
Lens directly at the sun; this could damage internal
parts of the unit.
15
