3.2 Connectors of the servo driver
U, V, W
U
V
W
MFMCA0xxxWJD ACS **/YY
Wiring of the XB connector for the motor power supply
X6 connector (encoder connector)
Connect the encoder cable to the X6 connector.
MFECA0xxxWJD ACS **/YY
Wiring of the X6 connector for the encoder connection
X1 connector (USB connector for PC connection)
The servo driver is configured using the PC configuration software PANATERM. Use a
commercially available USB A to mini-B cable to connect the PC to the servo driver.
Connector X1 for PC connection
QS5001_V1.0_EN 9
