Specifications
ENGLISH - 47
Appendix
Connectors
S-VIDEO IN
Single - line, Mini DIN 4p
Y: 1.0 V [p-p], C: 0.286 V [p-p], 75
Ω
VIDEO IN
Single - line, RCA pin jack
1.0 V [p-p], 75
Ω
PC IN
RGB Single - line, D - sub HD 15-pin
(female)
R.G.B.
0.7 V [p-p], 75
Ω
G.SYNC
1.0 V [p-p], 75
Ω
HD/SYNC TTL high impedance, automatic
positive/negative polarity compatible
VD TTL high impedance, automatic
positive/negative polarity compatible
COMPONENT IN
Y, P
B/CB, PR/CR Single - line, RCA pin jack x 3
Y:
1.0 V [p-p] (including sync), 75
Ω
PB/CB, (PR/CR)
0.7 V [p-p], 75 Ω
HDMI IN
Single - line, 19-pin HDMI connector
SERIAL
DIN 8-pin RS-232C compatible
Cabinet
Moulded plastic (ABS/PC)
Dimensions
Width 395 mm (15 -17/32")
Height 112 mm (4 - 13/32")
Length 300 mm (11 - 25/32")
Weight
4.9 kg (10.8 lbs.)
Operating environment
Temperature 0 °C - 40 °C (32 °F - 104 °F)
When the ALTITUDE (page 35) is set
to HIGH: 0°C - 35°C (32°F - 95°F)
Humidity 20% - 80% (no condensation)
Certifications
EN60950-1, EN55022, EN61000-3-2, EN61000-3-3,
EN55024
Remote control
Power supply
3 V DC (AA battery x 2)
Operating range
Approx. 7 m (23') (when operated directly in front of signal
receptor)
Weight
125 g (4.4 ozs.) (including batteries)
Dimensions
Width 48 mm (1 - 7/8")
Length 138 mm (5 - 13/32")
Height 28.35 mm (1-3/32") (not including
projecting parts)
Options
Ceiling bracket
ET-PKX100
Projection screen
ET-SRW90CT
Serial adapter
ET-ADSER (DIN 8-pin/D-sub 9-pin)
