Panasonic PT-AX200

S PEC F ILE
PT-AX200
High-Definition Home Cinema Projector
As of October 2008 < 2 >
Specifications
Main Unit
Power supply:
Power consumption:
LCD*
1
panel: Panel size:
Display method:
Drive method:
Pixels:
Lamp*
2
:
Lens:
Screen size:
Throw distance:
Colours:
Brightness*
3
:
Centre-to-corner uniformity ratio*
3
:
Contrast*
3
:
Resolution:
Scanning frequency: RGB:
YPBPR (YCBCR):
S-Video/Video:
Optical axis shift*
5
:
Keystone correction range:
Installation:
OSD languages:
Terminals: HDMI IN:
COMPUTER IN:
R, G, B:
HD/SYNC, VD:
COMPONENT IN:
Y:
PB/CB, PR/CR:
VIDEO IN:
S-VIDEO IN:
SERIAL IN:
100–240 V AC, 50/60 Hz
290 W (0.08 W in standby mode with fan stopped)
0.7˝ diagonal (16:9 aspect ratio)
Transparent LCD panel (x 3, R/G/B)
Active matrix
921,600 (1,280 x 720) x 3, total of 2,764,800 pixels
220 W UHM lamp
Manual zoom/focus lens (1:1 –1:2), F 1.9–3.1, f 21.7– 43.1 mm
40– 200 inches (1,016 – 5,080 mm) diagonally, 16:9 aspect ratio
1.2–12.4 m (3´11˝–40´8˝) (16:9 aspect ratio)
Full colour (1,073,741,824 colours)
2,000 lumens*
4
85 %
6,000:1*
4
(full on/full off)
1,280 x 720 pixels (1,920 x 1,080 pixels with compression)
fH 30–70 kHz, fV 50– 87 Hz
Dot clock: Less than 150 MHz
480i (525i): fH 15.75 kHz, fV 60 Hz
480p (525p): fH 31.5 kHz, fV 60 Hz
576i (625i): fH 15.63 kHz, fV 50 Hz
576p (625p): fH 31.25 kHz, fV 50 Hz
720/50p (750/50p): fH 45 kHz, fV 60 Hz
720/60p (750/60p): fH 37.5 kHz, fV 50 Hz
1080/50i (1125/50i): fH 28.125 kHz, fV 50 Hz
1080/50p (1125/50p): fH 56.3 kHz, fV 50 Hz
1080/24p (1125/24p): fH 27.0 kHz, fV 24 Hz
1080/60i (1125/60i): fH 33.75 kHz, fV 60 Hz
1080/60p (1125/60p): fH 67.5 kHz, fV 60 Hz
f
H 15.75 kHz, fV 60 Hz (NTSC, NTSC4.43, PAL-M, PAL60)
f
H 15.63 kHz, fV 50 Hz (PAL, PAL-N, SECAM)
Horizontal: ±25%, vertical: ±63%
Vertical: approx. ±30°
Ceiling/floor, front/rear
English, French, German, Spanish, Italian, Chinese, Korean, Russian,
Swedish, Danish, Norwegian, Polish, Czech, Hungarian, Portuguese,
Thai
HDMI connector x 2
D-sub HD 15-pin (female) x 1,
0.7 Vp-p (1.0 Vp-p for Sync on G), 75 ohms
TTL, high impedance (positive/negative polarity)
RCA pin (Y, PB/CB, PR/CR) x 1
1.0 p-p, 75 ohms
0.7 Vp-p, 75 ohms
RCA pin x 1, 1.0 Vp-p, 75 ohms
Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
Mini DIN 8-pin (female) x 1, for external control (RS-232C compliant)
