Panasonic PT-D3500E - J-P.C.board

16.3. J-P.C.Board
TXN/J1VKA3J-P.C.Board
(Foil side)
TXN/J1VKA3J-P.C.Board
(Component side)
IC9801
IC9802
IC9803
IC9804
IC9805
IC9806
IC9807
IC9808
IC9809
IC9810
A-2
A-1
B-1
B-5
B-2
A-3
B-4
B-4
B-4
B-2
ADDRESS INFORMATION
IC
J-P.C.Board (Component Side)
TRANSISTOR
Q9801
Q9802
Q9803
Q9804
Q9805
Q9806
Q9807
Q9808
Q9809
Q9810
Q9811
Q9812
B-4
B-4
B-4
A-4
B-5
B-5
B-3
B-3
B-3
B-3
B-3
B-3
PT-D3500U / PT-D3500E
75
